Wiring Diagrams for Lexus LS V facelift (2021-2024)

Acoustic vehicle altering system circuit Pedestrian protection system circuit

Automatic a/c circuit

Anti-lock brakes circuit Anti-lock brakes circuit, w/ ecb Anti-lock brakes circuit, w/o ecb

Forced entry circuit Immobilizer circuit

Body ecu circuit Integration control and panel circuit Semiconductor power integration ecu circuit

Computer data lines circuit Computer data lines circuit, w/ advanced park system Computer data lines circuit, w/o advanced park system

Battery cooling fan circuit Cooling fan circuit

Cruise control circuit

Front deicer circuit Rear defogger & heated mirrors circuit

Electronic power steering circuit Progressive power steering circuit

Active stabilizer suspension circuit Adaptive variable suspension circuit

Wiring diagram engine performance 3.4l turbo

Wiring diagram engine performance 3.5l hybrid, engine controls circuit Wiring diagram engine performance 3.5l hybrid, hybrid system circuit

Backup lamps circuit Exterior lamps circuit

Ground distribution circuit

Headlights circuit

Horn circuit

Instrument cluster circuit

Courtesy lamps circuit Instrument illumination circuit

Driver"s memory seat circuit Memory mirrors circuit Memory power tilt & power telescopic circuit Memory rear seat circuit Passenger"s memory seat circuit

Blind spot monitoring circuit Lane departure warning circuit Navigation circuit Parking assistant circuit Rear sonar circuit Telematics circuit

Passive restraints circuit

Power distribution circuit

Power door locks circuit

Power mirrors circuit

Front climate control seats circuit Front heated seats circuit Heated steering wheel circuit Rear climate control seats circuit Rear heated seats circuit

Panoramic roof circuit Sunroof circuit

Power windows circuit Rear window sun shade circuit

Radio circuit

Park brake release circuit Shift interlock circuit Steering column circuit

Charging circuit Starting circuit

Pre-collision circuit Supplemental restraint circuit

Transmission circuit

Fuel door release circuit Trunk opener & closer circuit Trunk opener & closer circuit, w/o power trunk lid Trunk opener & closer circuit, w/ power trunk lid

Seat belt warning circuit Tire pressure monitoring circuit

Front wiper/washer circuit Headlamp washer circuit

AIR CONDITIONING AMPLIFIER ASSEMBLY ANTI-LOCK BRAKES SYSTEM GENERATOR ASSEMBLY HIGH PITCHED HORN ASSEMBLY HV BATTERY JUNCTION BLOCK ASSEMBLY HYBRID BATTERY TERMINAL BLOCK HYBRID VEHICLE GENERATOR IGNITION COIL ASSEMBLY 1 IGNITION COIL ASSEMBLY 2 IGNITION COIL ASSEMBLY 3 IGNITION COIL ASSEMBLY 4 IGNITION COIL ASSEMBLY 5 IGNITION COIL ASSEMBLY 6 ION GENERATOR SUB-ASSEMBLY LEFT REAR DOOR LOCK ASSEMBLY LOW PITCHED HORN ASSEMBLY RIGHT REAR DOOR LOCK ASSEMBLY SECURITY HORN ASSEMBLY STARTER ASSEMBLY STEREO COMPONENT AMPLIFIER ASSEMBLY SUB-BATTERY W/ CONTROL SUB-BATTERY W/ CONTROL ASSEMBLY TELEMATICS TRANSCEIVER ASSEMBLY UPPER HYBRID VEHICLE BATTERY UPPER HYBRID VEHICLE BATTERY BUSBAR MODULE W/ DIODE W/O DIODE WIRELESS DOOR LOCK BUZZER

(RIGHT FRONT OF ENGINE (RIGHT SIDE OF ENGINE BEAM ACTUATOR BLOWER MOTOR W/ FAN SUB-ASSEMBLY COMPRESSOR W/ MOTOR ASSEMBLY ENGINE CONTROL SYSTEM ENGINE CONTROLS SYSTEM ENGINE ROOM J/B 1 ENGINE ROOM J/B 2 ENGINE ROOM R/B 1 ENGINE ROOM R/B 2 FAN MOTOR FAN W/ MOTOR ASSEMBLY FRONT ACTIVE STABILIZER CONTROL ACTUATOR ASSEMBLY FUEL LID LOCK W/ MOTOR ASSEMBLY HEADLAMP CLEANER MOTOR, PUMP ASSEMBLY HEADLIGHT CLEANER MOTOR, PUMP ASSEMBLY HYBRID VEHICLE MOTOR LEFT CAM TIMING OIL CONTROL MOTOR W/ EDU ASSEMBLY LEFT FRONT DOOR LOCK W/ MOTOR ASSEMBLY LEFT THROTTLE BODY W/ MOTOR ASSEMBLY LEVELING ACTUATOR LUGGAGE CLOSER MOTOR ASSEMBLY OIL PUMP MOTOR CONTROLLER PARKING BRAKE ACTUATOR W/ BRACKET ASSEMBLY REAR ACTIVE STABILIZER CONTROL ACTUATOR ASSEMBLY RIGHT CAM TIMING OIL CONTROL MOTOR W/ EDU ASSEMBLY RIGHT FRONT DOOR LOCK W/ MOTOR ASSEMBLY RIGHT THROTTLE BODY W/ MOTOR ASSEMBLY STEERING ACTUATOR ASSEMBLY STEERING LOCK ACTUATOR OR UPPER BRACKET ASSEMBLY STEERING LOCK ACTUATOR/ UPPER BRACKET ASSEMBLY SWIVEL ACTUATOR TELESCOPIC MOTOR THROTTLE BODY W/ MOTOR ASSEMBLY TILT MOTOR TOP OF ENGINE) WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY WINDSHIELD WIPER MOTOR ASSEMBLY

ELECTRICAL KEY ANTENNA INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 1 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 2 INDOOR ELECTRICAL KEY ANTENNA ASSEMBLY 3 ROOF HEADER ELECTRICAL KEY ANTENNA

LEFT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT FRONT POWER WINDOW REGULATOR SWITCH ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY

FORWARD RECOGNITION CAMERA FRONT TELEVISION CAMERA ASSEMBLY INNER MIRROR CAMERA ASSEMBLY LEFT SIDE TELEVISION CAMERA ASSEMBLY RIGHT SIDE TELEVISION CAMERA ASSEMBLY STEREO CAMERA TELEVISION CAMERA ASSEMBLY W/ MONO CAMERA W/ STEREO CAMERA W/O MONO CAMERA

DATA LINK CONNECTOR 3 PASSENGER POWER OUTLET SOCKET ASSEMBLY 1 POWER OUTLET SOCKET ASSEMBLY 1 POWER OUTLET SOCKET ASSEMBLY 2 REAR POWER OUTLET SOCKET ASSEMBLY 1

ABSORBER CONTROL ECU ACTIVE STABILIZER CONTROL ECU ASSEMBLY ADVANCED DRIVE EXTENSION ECU ASSEMBLY AIR BAG ECU ASSEMBLY BATTERY ECU ASSEMBLY CERTIFICATION ECU ASSEMBLY CLEARANCE WARNING ECU ASSEMBLY DRIVER SIDE J/B MAIN BODY ECU DRIVING SUPPORT ECU ASSEMBLY ECU-B D 1 FUSE ECU-B D 2 FUSE ECU-B P 1 FUSE ECU-B P 2 FUSE ECU-B P 3 FUSE ECU-B P 4 FUSE ECU-B P 5 FUSE ETHERNET SWITCHING HUB ECU ASSEMBLY 1 FRONT STEERING CONTROL ECU FUEL PUMP CONTROL ECU HYBRID VEHICLE CONTROL ECU ASSEMBLY LEFT FRONT MULTIPLEX NETWORK DOOR ECU LEFT FRONT POSITION CONTROL ECU ASSEMBLY LEFT HEADLIGHT ECU SUB-ASSEMBLY LEFT REAR MULTIPLEX NETWORK DOOR ECU LEFT REAR POSITION CONTROL ECU ASSEMBLY MAIN BODY ECU MULTIPLEX NETWORK DOOR ECU MULTIPLEX TILT, TELESCOPIC ECU NAVIGATION ECU NETWORK GATEWAY ECU OCCUPANT DETECTION ECU PARKING ASSIST ECU PARKING BRAKE ECU ASSEMBLY PEDESTRIAN DETECTION ECU ASSEMBLY PNEUMATIC VALVE CONTROL ECU PNK ECU WIRE REAR ACTIVE STABILIZER CONTROL ECU REAR STEERING CONTROL ECU RIGHT FRONT MULTIPLEX NETWORK DOOR ECU RIGHT FRONT POSITION CONTROL ECU ASSEMBLY RIGHT HEADLIGHT ECU SUB-ASSEMBLY RIGHT REAR MULTIPLEX NETWORK DOOR ECU RIGHT REAR POSITION CONTROL ECU ASSEMBLY SEAT BELT CONTROL ECU SEMICONDUCTOR POWER INTEGRATION ECU 1 SEMICONDUCTOR POWER INTEGRATION ECU 2 SEMICONDUCTOR POWER INTEGRATION ECU 3 SHIFT CONTROL ECU SKID CONTROL ECU ASSEMBLY SUSPENSION CONTROL ECU

A/BAG FUSE A/C 1 FUSE A/C 2 FUSE A/C RR FUSE A/F HTR 1 FUSE A/F HTR 2 FUSE A/F HTR FUSE ABS MAIN 2 FUSE ABS MAIN 3 FUSE ABS MTR 1 FUSE ABS MTR 2 FUSE ABS- MAIN 1 FUSE ACC D FUSE ACC P 1 FUSE ACC P 2 FUSE AIRSUS 1 FUSE AIRSUS 2 FUSE ALT FUSE AMP 1 FUSE AMP 2 FUSE ARS FUSE AVS FUSE BATT FAN 1 FUSE BCC 4 FUSE CAMERA CLN FUSE CAMERA CLN RR FUSE CAPACITOR FUSE D/C CUT 1 FUSE D/C CUT 2 FUSE D/L FUSE DC/ DC-S FUSE DC/DC FUSE DC/DC-S FUSE DCM FUSE DEICER FUSE DOME D FUSE DOME P FUSE DOOR D 1 FUSE DOOR D 2 FUSE DOOR D 3 FUSE DOOR P 1 FUSE DOOR P 2 FUSE DOOR P 3 FUSE DOOR R/L 1 FUSE DOOR R/L 2 FUSE DOOR R/R 1 FUSE DOOR R/R 2 FUSE E MIR FUSE EDU 1 FUSE EDU 2 FUSE EDU 3 FUSE EDU 4 FUSE EDU FUSE EFI 1 FUSE EFI 2 FUSE EFI 3 FUSE EFI 4 FUSE EFI- B 4 FUSE EFI- MAIN 1 FUSE EFI- MAIN 2 FUSE EFI- MAIN 3 FUSE EFI-B 1 FUSE EFI-B 2 FUSE EFI-B 3 FUSE ENG FUSE EPB 1 FUSE EPB 3 FUSE EPS FUSE ETCS 1 FUSE ETCS 2 FUSE ETCS FUSE ETS FUSE FAN 1 FUSE FUEL OPN FUSE GRILL SHUTTER FUSE H-LP CLN FUSE HAZ FUSE HORN FUSE HTR FUSE ICS FUSE IGCT 1 FUSE IGCT 2 FUSE IGCT 3 FUSE IGCT 4 FUSE IGCT 5 FUSE IGCT 6 FUSE IGN FUSE INJ FUSE INV FUSE INV W/ PMP FUSE J/B D-ALT FUSE J/B D-B FUSE J/B P-ALT FUSE J/B P-B FUSE LUG CLOSER FUSE LUG- ACC 1 FUSE LUG- ACC 2 FUSE LUG- B 4 FUSE LUG- B 5 FUSE LUG-B 1 FUSE LUG-B 2 FUSE LUG-B 6 FUSE METER FUSE MG FUSE MPX-B D 1 FUSE MPX-B D 1 MPX-B D 2 FUSE MPX-B D 2 FUSE MPX-B P 1 FUSE MPX-B P 2 FUSE OBD FUSE OIL PMP FUSE P CON MAIN 2 FUSE P CON MAIN FUSE P CON MTR 2 FUSE P CON MTR FUSE P/ OUTLET 1 FUSE P/I 1 FUSE P/I 2 FUSE P/I 3 FUSE P/OUTLET 2 FUSE P/OUTLET 3 FUSE P/OUTLET 4 FUSE P/SEAT D 1 FUSE P/SEAT D 2 FUSE P/SEAT P 1 FUSE P/SEAT P 2 FUSE P/SEAT R/L 1 FUSE P/SEAT R/L 2 FUSE P/SEAT R/R 1 FUSE P/SEAT R/R 2 FUSE PANEL D FUSE PANEL P FUSE PM IGCT FUSE PSB 1 FUSE PTL FUSE R/B FR FUSE R/B RR 1 FUSE R/B RR 2 FUSE R/B RR 3 FUSE R/B- ALT FUSE R/B-B FUSE RADIO 1 FUSE RADIO 2 FUSE RSE 1 FUSE RSE 2 FUSE S-HORN FUSE S/ HTR D FUSE S/ ROOF 1 FUSE S/HTR D FUSE S/HTR P FUSE S/HTR R/L FUSE S/HTR RR FUSE S/ROOF 1 FUSE S/ROOF 2 FUSE S/ROOF 3 FUSE SEAT R/L FUSE SEAT R/R FUSE SHADE RR FUSE SMART FUSE ST 1 FUSE STAB CUT FUSE STAB FR FUSE STAB RR FUSE STOP FUSE STRG LOCK FUSE TI, TE FUSE TV FUSE VGRS FUSE VSC 1 FUSE VSC 2 FUSE WASHER FUSE WIPER 1 FUSE WSH NZL HTR FUSE

FORWARD RECOGNITION W/ HEATER HOOD SUB-ASSEMBLY LEFT FRONT SEAT HEATER ASSEMBLY LEFT FRONT SEAT HEATER CONTROL SUB-ASSEMBLY LEFT REAR SEAT BACK HEATER ASSEMBLY LEFT REAR SEAT HEATER ASSEMBLY LEFT REAR SEAT HEATER CONTROL SUB-ASSEMBLY MIRROR HEATER QUICK HEATER ASSEMBLY RIGHT FRONT SEAT HEATER ASSEMBLY RIGHT FRONT SEAT HEATER CONTROL SUB-ASSEMBLY RIGHT REAR SEAT BACK HEATER ASSEMBLY RIGHT REAR SEAT HEATER ASSEMBLY RIGHT REAR SEAT HEATER CONTROL SUB-ASSEMBLY STEERING HEATER

AUTOMATIC HIGH BEAM INDICATOR BLIND SPOT MONITOR INDICATOR FRONT PAD WEAR INDICATOR RIGHT PAD WEAR INDICATOR RIGHT REAR PAD WEAR INDICATOR SHIFT POSITION INDICATOR

DOOR LOCKS ANTI-THEFT, POWER WINDOWS, INTERIOR LIGHTS, AIR CONDITIONING SYSTEMS DOOR LOCKS, ANTI-THEFT, INTERIOR LIGHTS SYSTEMS LIGHTS)

BRAKE BOOSTER PUMP W/ ACCUMULATOR ASSEMBLY ELECTRIC WATER PUMP ASSEMBLY FUEL PUMP ASSEMBLY FUEL PUMP ASSEMBLY SHIELD LEAK DETECTION PUMP SUB-ASSEMBLY LEFT FRONT LUMBAR SUPPORT PUMP SUB-ASSEMBLY LEFT FUEL PUMP ASSEMBLY LEFT FUEL PUMP ASSEMBLY SHIELD LEFT REAR LUMBAR SUPPORT PUMP SUB-ASSEMBLY RIGHT FUEL PUMP ASSEMBLY RIGHT FUEL PUMP ASSEMBLY SHIELD RIGHT REAR LUMBER SUPPORT PUMP SUB-ASSEMBLY

A/F HTR RELAY ABS MTR 1 RELAY ABS MTR 2 RELAY ACC D RELAY ACC P 2 RELAY ACC P RELAY AIRSUS RELAY ALL DR LOCK RELAY BATT FAN 1 RELAY CAMERA CLN RELAY D 1 RELAY ENERGIZED D 2 RELAY ENERGIZED D DR UNLOCK RELAY D RELAY ENERGIZED DEICER RELAY DEICER RELAY ENGINE ROOM R/B 2 DOME CUT D RELAY DOME CUT P RELAY EDU RELAY EFI MAIN 2 RELAY EFI- MAIN 1 RELAY EFI- MAIN 3 RELAY FUEL LID OPN RELAY H-LP CLN RELAY HORN RELAY HOT W/ ACC D RELAY ENERGIZED HOT W/ ACC P RELAY ENERGIZED HOT W/ IGCT 1 RELAY ENERGIZED HOT W/ LUG-ACC RELAY ENERGIZED IGCT 1 RELAY IGCT 2 RELAY INV RELAY INV W/ PMP RELAY L/D-DR UNLOCK RELAY LUG- ACC RELAY MAIN RELAY OIL PMP RELAY OIL PUMP RELAY P 1 RELAY ENERGIZED P 2 RELAY ENERGIZED P CON MTR 2 RELAY P CON MTR RELAY P/OUTLET RELAY 3 P/OUTLET RELAY 4 PANEL D RELAY PANEL P RELAY PRECHARGE RELAY RELAY ENERGIZED S-HORN RELAY ST 1 RELAY VVT 1 RELAY VVT 2 RELAY WIPER 1 RELAY WIPER RELAY 1

A/C EVAPORATOR TEMPERATURE SENSOR ACCELERATOR PEDAL SENSOR ASSEMBLY AIR CONDITIONING PRESSURE SENSOR AUTOMATIC LIGHT CONTROL SENSOR BATTERY STATE SENSOR ASSEMBLY CRANK POSITION SENSOR CURRENT SENSOR E.F.I. ENGINE COOLANT TEMPERATURE SENSOR E.F.I. ENGINE COOLANT TEMPERATURE SENSOR 1 E.F.I. ENGINE COOLANT TEMPERATURE SENSOR 2 EFI VACUUM SENSOR ASSEMBLY ENGINE COOLANT TEMPERATURE SENSOR ENGINE OIL LEVEL SENSOR FRONT HEIGHT CONTROL PRESSURE SENSOR KICK DOOR CONTROL SENSOR LEFT ACCELERATION SENSOR ASSEMBLY LEFT AIR CONDITIONING INFRARED RAYS SENSOR LEFT BLIND SPOT MONITOR SENSOR LEFT DOOR SIDE AIR BAG SENSOR LEFT EFI VACUUM SENSOR ASSEMBLY LEFT FRONT AIR BAG SENSOR LEFT FRONT CENTER ULTRASONIC SENSOR LEFT FRONT CORNER ULTRASONIC SENSOR LEFT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY LEFT FRONT OCCUPANT CLASSIFICATION SENSOR LEFT FRONT SIDE RADAR SENSOR LEFT FRONT SPEED SENSOR LEFT REAR AIR BAG SENSOR ASSEMBLY LEFT REAR CENTER ULTRASONIC SENSOR LEFT REAR CORNER ULTRASONIC SENSOR LEFT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY LEFT REAR OCCUPANT CLASSIFICATION SENSOR LEFT REAR SPEED SENSOR LEFT SEAT POSITION AIR BAG SENSOR LEFT SIDE AIR BAG SENSOR ASSEMBLY LEFT SIDE AIR BAG SENSOR ASSEMBLY 2 LEFT TURBO PRESSURE SENSOR 1 LEFT TURBO PRESSURE SENSOR 2 MILLIMETER WAVE RADAR SENSOR ASSEMBLY MOTOR ROTATION ANGLE SENSOR RAIN SENSOR REAR HEIGHT CONTROL PRESSURE SENSOR RIGHT ACCELERATION SENSOR ASSEMBLY RIGHT AIR CONDITIONING INFRARED RAYS SENSOR RIGHT BLIND SPOT MONITOR SENSOR RIGHT DOOR SIDE AIR BAG SENSOR RIGHT EFI VACUUM SENSOR ASSEMBLY RIGHT FRONT AIR BAG SENSOR RIGHT FRONT CENTER ULTRASONIC SENSOR RIGHT FRONT CORNER ULTRASONIC SENSOR RIGHT FRONT HEIGHT CONTROL SENSOR SUB-ASSEMBLY RIGHT FRONT SIDE RADAR SENSOR RIGHT FRONT SKID CONTROL SENSOR WIRE RIGHT FRONT SPEED SENSOR RIGHT REAR AIR BAG SENSOR ASSEMBLY RIGHT REAR CENTER ULTRASONIC SENSOR RIGHT REAR CORNER ULTRASONIC SENSOR RIGHT REAR HEIGHT CONTROL SENSOR SUB-ASSEMBLY RIGHT REAR SKID CONTROL SENSOR WIRE RIGHT REAR SPEED SENSOR RIGHT SIDE AIR BAG SENSOR ASSEMBLY RIGHT SIDE AIR BAG SENSOR ASSEMBLY 2 RIGHT TURBO PRESSURE SENSOR 1 RIGHT TURBO PRESSURE SENSOR 2 SMOG VENTILATION SENSOR SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY STEERING SENSOR STEERING TORQUE SENSOR BOARD SUB-ASSEMBLY STROKE SENSOR TELESCOPIC SENSOR TILT SENSOR TORQUE SENSOR TRANSMISSION REVOLUTION SENSOR TURBO PRESSURE SENSOR 3 VAPOR PRESSURE SENSOR ASSEMBLY YAW RATE SENSOR

CAN I/F SPEAKER FRONT SPEAKER ASSEMBLY 3 LEFT FRONT ROOF SPEAKER ASSEMBLY LEFT FRONT SPEAKER ASSEMBLY 1 LEFT FRONT SPEAKER ASSEMBLY 2 LEFT REAR ROOF SPEAKER ASSEMBLY LEFT REAR SPEAKER ASSEMBLY LEFT REAR SPEAKER ASSEMBLY 2 REAR SPEAKER ASSEMBLY 3 RIGHT FRONT ROOF SPEAKER ASSEMBLY RIGHT FRONT SPEAKER ASSEMBLY 1 RIGHT FRONT SPEAKER ASSEMBLY 2 RIGHT REAR ROOF SPEAKER ASSEMBLY RIGHT REAR SPEAKER ASSEMBLY RIGHT REAR SPEAKER ASSEMBLY 2 VEHICLE APPROACHING SPEAKER ASSEMBLY VEHICLE APPROACHING SPEAKER CONTROLLER

AUTOMATIC HIGH BEAM SWITCH BRAKE HOLD SWITCH BRAKE PEDAL LOAD SENSING SWITCH DIMMER SWITCH DOOR CONTROL SWITCH DOWN SWITCH ECO MODE SWITCH ELECTRIC PARKING BRAKE SWITCH ASSEMBLY ENGINE OIL PRESSURE SWITCH ASSEMBLY ENGINE SWITCH EV MODE SWITCH FRONT WASHER SWITCH FRONT WIPER SWITCH HORN SWITCH INT VOLUME SWITCH INTER LOCK SWITCH INTERLOCK SWITCH LDA SWITCH LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT FRONT POWER SEAT SWITCH LEFT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY LEFT SEAT MEMORY SWITCH LEFT STEERING SWITCH LIGHT CONTROL SWITCH LIGHT CONTROL SWITCH TURN SIGNAL SWITCH LUGGAGE DOOR OPENING CANCEL SWITCH ASSEMBLY MULTIPLEX NETWORK MASTER SWITCH ASSEMBLY NON-CONTACT SWITCH NORMAL SWITCH POWER SWITCH ANTENNA COIL REAR FOG LIGHT SWITCH RIGHT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT FRONT POWER SEAT SWITCH RIGHT REAR DOOR COURTESY LIGHT SWITCH ASSEMBLY RIGHT SEAT MEMORY SWITCH RIGHT STEERING SWITCH SATELLITE SWITCH SET SATELLITE SWITCH SET 2 SNOW SWITCH SPORT MODE SWITCH SPORT SWITCH STEERING PAD SWITCH ASSEMBLY STEERING WHEEL SWITCH HOUSING STOP LIGHT SWITCH ASSEMBLY TELESCO SHORTEN SWITCH TELESCO STRETCH SWITCH TILT DOWN SWITCH TILT UP SWITCH TILT, TELESCOPIC SWITCH TRANSMISSION SHIFT SWITCH TRANSMISSION SHIFT SWITCH ASSEMBLY TRIP SWITCH TRUNK, FUEL SWITCH ASSEMBLY TURN SIGNAL SWITCH TURN SWITCH UP SWITCH VACUUM WARNING SWITCH ASSEMBLY VSC OFF SWITCH W/ HEADREST UP/DOWN SWITCH WINDSHIELD WIPER SWITCH ASSEMBLY

EGR VALVE ASSEMBLY EXHAUST SIDE HEIGHT CONTROL VALVE FUEL TANK SOLENOID MAIN VALVE ASSEMBLY HEIGHT CONTROL VALVE EXHAUST SIDE HEIGHT CONTROL VALVE SUB ASSEMBLY 1 HEIGHT CONTROL VALVE SUB- ASSEMBLY 2 HEIGHT CONTROL VALVE SUB-ASSEMBLY 3 LEFT AIR BY-PASS VALVE ASSEMBLY RIGHT AIR BY-PASS VALVE ASSEMBLY WATER CONTROL VALVE

(OR RED/ WIRE ACL PNK RBR- WIRE BLK WIRE BLK/BLU WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU WIRE BRN WIRE BRN/WHT WIRE CANH PNK HCTY WIRE EPA PNK VCPA WIRE FL- PPL/PNK FR- WIRE FLCL PNK HCTY WIRE GRN WIRE GRY WIRE GRY/RED WIRE H+ PNK HD+ WIRE HAZ PNK WIRE HEDD/SLRS PNK WIRE HEDU PNK HEDD WIRE LFTU PNK LFTD WIRE LIN PNK CANP WIRE LT BLU WIRE LT GRN OR PNK WIRE LT GRN WIRE NCA WIRE ORG/ WIRE ORG/BLK WIRE ORG/WHT WIRE PNK +B WIRE PNK CANH WIRE PNK CPSE WIRE PNK HCTY WIRE PNK PNK WIRE PNK SHD + WIRE PNK SSHD PNK SSRH WIRE PNK TAIL WIRE PNK TSR WIRE PNK WIRE PPL/BLK WIRE PPL/BLU WIRE PPL/BRN WIRE PPL/GRN WIRE PPL/GRY WIRE PPL/LT BLU WIRE PPL/LT GRN WIRE PPL/ORG WIRE PPL/PNK WIRE PPL/RED WIRE PPL/VIO WIRE PPL/WHT WIRE PPL/YEL WIRE REAR CONSOLE BOX WIRE RED WIRE SSLB PNK SSRC WIRE UL PNK LSSR WIRE VIO WIRE VIO/GRN WIRE VIO/WHT WIRE WHT WIRE WHT/BLK WIRE WSR- PNK WIRE YEL WIRE YEL/BLK WIRE YEL/GRN WIRE YEL/RED WIRE

1) LEFT TURN 2) LEFT LANE CHANGE 3) NEUTRAL 4) RIGHT LANE CHANGE 5) RIGHT TURN (IF (NOT +BC +BCP +BI +BM +BO +BWP -TW ACPE SHIELD AE AM AI AE AIR CONDITIONING CONTROL ASSEMBLY AIR CONDITIONING HARNESS ASSEMBLY AIR CONDITIONING SYSTEM AIR CONDITIONING, HEADLIGHTS SYSTEMS ANTI-THEFT SYSTEM ASH- AUTO OFF AUTO TAIL B+ BUS BACKUP LAMPS CIRCUIT BAT+ BBL+ BBR+ BBR+ BCR+ BCR- BCB+ BCL+ BCR+ BCV- BDL- BDR PPL GND BFL+ BFR+ BMU+ BMV+ BMW+ BRAKE CONTROL POWER SUPPLY W/ BRACKET ASSEMBLY BSR+ BU+B BUS - BUS G BUSBAR MODULE CA+ CAN I/F CAN JUNCTION TERMINAL 1 CAN JUNCTION TERMINAL 2 CAN JUNCTION TERMINAL 3 CAN JUNCTION TERMINAL 5 CAN JUNCTION TERMINAL 6 CAN JUNCTION TERMINAL 7 CAN JUNCTION TERMINAL 8 CAN JUNCTION TERMINAL 10 CB+ CB+ CEB+ CBR+ CEB+ CENTER REAR SEAT INNER BELT ASSEMBLY CENTER STOP LIGHT ASSEMBLY CEV- CGND CEG CHECK E/G IND CLEARANCE LIGHT CLEARANCE WARNING BUZZER 1 CLEARANCE WARNING BUZZER 2 CLOCK ASSEMBLY COIN BOX LIGHT ASSEMBLY COMBINATION METER ASSEMBLY COMMUNICATION IC COMPRESSOR W/ PULLEY ASSEMBLY COMPUTER DATA LINES COMPUTER DATA LINES SYSTEM COMPUTER DATA LINES SYSTEMS CONSOLE BOX ILLUMINATION LIGHT ASSEMBLY COOLING FANS SYSTEM CORNERING LIGHT CPS+ CRUISE CONTROL SYSTEM CRUISE CONTROL SYSTEM PPL CSW+ CTR + CUS+ CV+ CV+ CEV+ DAYTIME RUNNING LIGHT DAYTIME RUNNING LIGHT CLEARANCE LIGHT DEFOGGER SYSTEM DGS 1 DISC PLAYER ASSEMBLY DISK PLAYER ASSEMBLY DISPLAY DRIVER DK+ DOOR LOCKS SYSTEM DOOR LOCKS, ANTI-THEFT SYSTEMS DRIVER DISPLAY DRIVER SIDE J/B EC+ ECC DIST ECI+ ECM SHIELD ECO MODE ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY ELECTRONIC SUSPENSION SYSTEM ELED BLED ES IG+ ETR+ ETT+ EV MODE EX+ EXCEPT HYBRID EXCEPT HYBRID HYBRID EXCEPT HYBRID W/ ACTIVE STABILIZER SUSPENSION SYSTEM F GND FAL+ FAR- FCM+ FE, B FLA- FP- FR FV FRONT ACTIVE FRR+ FRV- FSW+ FUEL DOOR RELEASE CIRCUIT FUEL SENDER GAGE ASSEMBLY 2 FUSIBLE LINK BLOCK ASSEMBLY FUSIBLE LINK BLOCK ASSEMBLY 1 FUSIBLE LINK BLOCK ASSEMBLY 2 GA GD GLOVE BOX LIGHT ASSEMBLY GND CTY GV- GVI- GVO+ HALL IC 1 HALL IC 2 HEAD ESS HEAD OFF HEADLIGHTS SYSTEM HEIGHT CONTROL COMPRESSOR 1 HEIGHT CONTROL COMPRESSOR THERMISTOR ASSEMBLY HF HU HF HU HL HORNS SYSTEM HOT AT ALL TIMES HOT W/ HOT W/ LUG- HYBRID EXCEPT HYBRID I/F I/F I/F TELLTALES ICL- ICR+ ID CODE BOX IL+1 IL+2 IL-1 IL-2 ILL CH ILL ILL INNER REAR VIEW MIRROR ASSEMBLY INSTRUMENT CLUSTER FINISH PANEL GARNISH ASSEMBLY INSTRUMENT CLUSTER SYSTEM INSTRUMENT PANEL PASSENGER AIR BAG W/O DOOR ASSEMBLY INT IF INTAKE MASS AIR FLOW METER SUB-ASSEMBLY INTEGRATION CONTROL, PANEL ASSEMBLY INTERIOR ILLUMINATION LIGHT ASSEMBLY 3 INVERTER BUS-BAR PLATE SUB- ASSEMBLY INVERTER W/ CONVERTER ASSEMBLY L OFF LBR- LCB+ LCM+ LCN+ LCV- LED DRIVER LED DRIVER CAN I/F LEFT "C" PILLAR) LEFT CURTAIN SHIELD AIR BAG ASSEMBLY LEFT CURTAIN SHIELD AIR BAG ASSEMBLY SHIELD LEFT FRONT DOOR COURTESY LIGHT ASSEMBLY LEFT FRONT DOOR OUTSIDE HANDLE ASSEMBLY LEFT FRONT SEAT AIR BAG ASSEMBLY LEFT FRONT SEAT INNER BELT ASSEMBLY LEFT FRONT SHOCK ABSORBER ASSEMBLY LEFT HEADLAMP ASSEMBLY LEFT INTAKE MASS AIR FLOW METER SUB-ASSEMBLY LEFT LICENSE PLATE LIGHT ASSEMBLY LEFT OUTER REAR VIEW MIRROR ASSEMBLY LEFT PEDESTRIAN DETECTION CHAMBER ASSEMBLY LEFT POP UP HOOD LIFTER ASSEMBLY LEFT POP UP HOOD LIFTER ASSEMBLY 2 LEFT REAR COMBINATION LIGHT ASSEMBLY LEFT REAR CURTAIN SUB-ASSEMBLY LEFT REAR DOOR COURTESY LIGHT ASSEMBLY LEFT REAR DOOR OUTSIDE HANDLE ASSEMBLY LEFT REAR LIGHT ASSEMBLY LEFT REAR SEAT AIR BAG ASSEMBLY LEFT REAR SEAT BACK CLIMATE CONTROL BLOWER LEFT REAR SEAT CUSHION AIR BAG ASSEMBLY LEFT REAR SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY LEFT REAR SEAT INNER BELT ASSEMBLY LEFT REAR SHOCK ABSORBER ASSEMBLY LEFT SEAT BACK CLIMATE CONTROL BLOWER LEFT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY LEFT SIDE TURN SIGNAL LIGHT ASSEMBLY LEFT TELEVISION DISPLAY ASSEMBLY LEFT TENSION REDUCER LEFT TURN IND LEFT VANITY LIGHT ASSEMBLY LEFT VANITY MIRROR ASSEMBLY LEFT VISOR ASSEMBLY LFT- LG+ LH - LOW/HI LED LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 1 LOWER INSTRUMENT PANEL AIR BAG ASSEMBLY 2 LSP + LSP- LSP+ LUGGAGE COMPARTMENT LIGHT ASSEMBLY LUGGAGE DOOR CLOSER ASSEMBLY LUGGAGE ROOM J/B 1 LUGGAGE ROOM J/B 2 LUGGAGE ROOM R/B 1 LUGGAGE ROOM R/B 2 MAP LIGHT ASSEMBLY MAP LIGHT SUB-ASSEMBLY MCI- MCO- MEMORY SYSTEMS METER HOOD ILLUMINATION LIGHT ASSEMBLY METER MIRROR SUB-ASSEMBLY MI+ MI- SHIELD SLDI MIC - MICROPHONE 2 + MO- MO- SHIELD SLDO MOR+ MPX-B P 1 MSM+ MULTI-DISPLAY MULTI-DISPLAY CONTROLLER SUB-ASSEMBLY NAVIGATION SYSTEM NAVIGATION, SOUND SYSTEMS NE+ NOISE CONTROL NON-CONTACT NOT USED OTE+ P-AB PAON PASSENGER SIDE J/B PASSIVE RESTRAINTS SYSTEM PB SHIELD PCB PC PK- PL- PLL- PLR+ POWER DISTRIBUTION SYSTEM POWER TOPS SYSTEM POWER WINDOWS SYSTEM PPL BRGD PPL EHT PPL ES PPL EXCEPT HYBRID PPL GB PPL GD PPL GND PPL HYBRID PPL LBR- PPL LD PPL RBR- PR- PRR- PSL+ PTL- PTR+ PUL- PURGE VSV R - L - R+ R- RADIO RECEIVER ASSEMBLY RAL+ RAR+ RBE+ RBR- RCB+ RCL- REAR OF LUGGAGE COMPT) REAR SEAT HEADREST ADJUSTER SUB-ASSEMBLY 1 REAR SEAT HEADREST ADJUSTER SUB-ASSEMBLY 2 REAR STEERING LINK ASSEMBLY REMOTE OPERATION CONTROLLER ASSEMBLY RG+ RH- RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY SHIELD RIGHT END OF DASH) RIGHT FRONT DOOR COURTESY LIGHT ASSEMBLY RIGHT FRONT DOOR OUTSIDE HANDLE ASSEMBLY RIGHT FRONT SEAT AIR BAG ASSEMBLY RIGHT FRONT SEAT INNER BELT ASSEMBLY RIGHT FRONT SHOCK ABSORBER ASSEMBLY RIGHT HEADLAMP ASSEMBLY RIGHT INTAKE MASS AIR FLOW METER SUB-ASSEMBLY RIGHT LICENSE PLATE LIGHT ASSEMBLY RIGHT OUTER REAR VIEW MIRROR ASSEMBLY RIGHT PEDESTRIAN DETECTION CHAMBER ASSEMBLY RIGHT POP UP HOOD LIFTER ASSEMBLY RIGHT POP UP HOOD LIFTER ASSEMBLY 2 RIGHT REAR COMBINATION LIGHT ASSEMBLY RIGHT REAR CURTAIN SUB-ASSEMBLY RIGHT REAR DOOR RIGHT REAR DOOR COURTESY LIGHT ASSEMBLY RIGHT REAR DOOR OUTSIDE HANDLE ASSEMBLY RIGHT REAR LIGHT ASSEMBLY RIGHT REAR SEAT AIR BAG ASSEMBLY RIGHT REAR SEAT BACK CLIMATE CONTROL BLOWER RIGHT REAR SEAT CUSHION AIR BAG ASSEMBLY RIGHT REAR SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY RIGHT REAR SEAT INNER BELT ASSEMBLY RIGHT REAR SEAT INNER BELT W/ CENTER ASSEMBLY RIGHT REAR SEAT RECLINING ADJUSTER SUB-ASSEMBLY RIGHT REAR SHOCK ABSORBER ASSEMBLY RIGHT SEAT BACK CLIMATE CONTROL BLOWER RIGHT SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY RIGHT SIDE TURN SIGNAL LIGHT ASSEMBLY RIGHT TELEVISION DISPLAY ASSEMBLY RIGHT TENSION REDUCER RIGHT TURN IND RIGHT VANITY LIGHT ASSEMBLY RIGHT VANITY MIRROR ASSEMBLY RIGHT VISOR ASSEMBLY RLA- RLR+ RM+ ROUT LOUT RRA+ RRR + RV+ RWD AWD SEATS SYSTEM SERVICE PLUG GRIP SFL- SFR- SG-1 SG-2 SG-4 SG-5 SG-6 SG-7 SHIFT INTERLOCK SYSTEM SHIFT INTERLOCK, TRANSMISSIONS SYSTEMS SHP+ SHS+ SIG 3 SL- SLT- SLU+ SP- SPI+ SPO- SPORT MODE SPOT LIGHT ASSEMBLY SR- SRL- SRR+ ST+ STARTING/ CHARGING SYSTEM STARTING/CHARGING SYSTEM STEERING COLUMN ASSEMBLY STEERING COLUMN) STEREO COMPONENT EQUALIZER ASSEMBLY STEREO JACK ADAPTER ASSEMBLY 1 SUPPLEMENTAL RESTRAINTS SYSTEM SVC 1 SVC 3 TAIL AUTO HEAD TC-E TELEPHONE MICROPHONE ASSEMBLY TELLTALE LIGHT ASSEMBLY TELLTALES FLASHER CIRCUIT TL TR TR TL TRANSMISSIONS SYSTEM TRN+ TRUNK, TAILGATE, FUEL DOORS SYSTEM TSR/SHP+ TURBOCHARGER SUB-ASSEMBLY 1 TURBOCHARGER SUB-ASSEMBLY 2 TURN L IND TURN R IND TWL- TWR+ TX+1 TX+ RLIN TX-1 UDO+ USED) VCSK SHIELD FSS VOLTAGE INVERTER ASSEMBLY VOR- VOT+ VV- VVL+ VVR+ W-OFF W/ ADAPTIVE FRONT LIGHTING SYSTEM W/ ADAVANCED DRIVE SYSTEM W/ ADVANCE PARK SYSTEM W/ ADVANCED DRIVE SYSTEM W/ AIR SUSPENSION W/ DIGITAL INNER MIRROR W/ DOOR CLOSER W/ ECB W/ LEFT SIDE REAR PASSENGER'S SEAT W/ PANORAMIC ROOF W/ REAR POWER SEAT W/ REAR SEAT ENTERTAINMENT SYSTEM W/ RIGHT SIDE REAR PASSENGER'S SEAT W/ TELEMATICS SYSTEM W/ VGRS W/O VGRS W/ VIBRATION SEAT SYSTEM W/O ADAVANCED DRIVE SYSTEM W/O ADVANCE PARK SYSTEM W/O ADVANCED DRIVE SYSTEM W/O ADVANCED PARK SYSTEM W/O AIR SUSPENSION W/O DOOR CLOSER W/O DOOR CLOSER W/ DOOR CLOSER W/O ECB W/O PANORAMIC ROOF W/O POWER TRUNK LID W/O REAR POWER SEAT W/O REAR SEAT ENTERTAINMENT SYSTEM W/O TELEMATICS SYSTEM W/O VGRS W/O VIBRATION SEAT SYSTEM WARNING SYSTEMS WFL- WFR- WGM- WIPER/WASHER SYSTEM
