Lexus LS V (2017-2021) transmission shift switch assembly Wiring diagrams
This page contains all the electrical diagrams for the component. transmission shift switch assembly, in which he is found in the car Lexus LS V (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram transmission shift switch assembly (1 of 2)
ACC P 1 FUSE
BAT+
BLK WIRE
BLK/WHT WIRE
BLK/YEL WIRE
BLU WIRE
BU+B
BUBI
BUBO
CERTIFICATION ECU ASSEMBLY
COMPUTER DATA LINES SYSTEM
DOWN
FUSIBLE LINK BLOCK ASSEMBLY 2
GRN WIRE
HOT AT ALL TIMES
HOT W/
HOT W/ ACC P RELAY ENERGIZED
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM J/B 1
LUGGAGE ROOM R/B 1
ORG/ WIRE
P CON MAIN 2 FUSE
P CON MTR 2 FUSE
P CON MTR 2 RELAY
PASSENGER SIDE J/B
PNK WIRE
PPL
PPL/GRN WIRE
PPL/RED WIRE
PPOS
R/B RR 1 FUSE
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
SBFS
SDN
SEMICONDUCTOR POWER INTEGRATION ECU 3
SHIFT CONTROL ECU
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
SUB-BATTERY W/ CONTROL ASSEMBLY
SUP
TRANSMISSION SHIFT SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Transmission circuit (1 of 4) -> TRANSMISSION SHIFT SWITCH ASSEMBLY
Wiring diagram transmission shift switch assembly (2 of 2)
BLK WIRE
BLPE
BLPU
BLPV
BLPW
BLU WIRE
BRN WIRE
CERTIFICATION ECU ASSEMBLY
D RELAY ENERGIZED
DOWN
DRIVER SIDE J/B
FPC
FPG
FPU
FPV
FPW
FUEL PUMP ASSEMBLY (FUEL TANK ASSEMBLY)
GRN WIRE
HOT AT ALL TIMES
LT BLU WIRE
LT GRN WIRE
ORG/ WIRE
PNK WIRE
PPL
PPL/BLK WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/WHT WIRE
RED WIRE
SATELLITE SWITCH SET 2
SBFS
SDN
SHIFT CONTROL ECU
SKSW
SNSW
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
STOP FUSE
STOP LIGHT SWITCH ASSEMBLY
SUP
TRANSMISSION SHIFT SWITCH ASSEMBLY
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.4l turbo (2 of 10) -> TRANSMISSION SHIFT SWITCH ASSEMBLY
