Lexus LS V (2017-2021) right vanity mirror assembly wiring diagram
This page shows the only wiring diagram for the component.right vanity mirror assembly, which is found in the car Lexus LS V (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
right vanity mirror assembly wiring diagram (1 of 1)
BLK WIRE
BLU WIRE
DOME
FLVS
FRVS
GB (DRIVER DOOR SILL)
GNDB
GRN WIRE
IL+1
IL+2
IL-1
IL-2
LEFT SPOT LIGHT ASSEMBLY (EXCEPT HYBRID W/ PANORAMIC ROOF)
LEFT VANITY LIGHT ASSEMBLY
LEFT VANITY MIRROR ASSEMBLY
LEFT VISOR ASSEMBLY
LILL
MAP LIGHT SUB-ASSEMBLY
PPL/BLK WIRE
PPL/BLU WIRE
PPL/BRN WIRE
PPL/GRN WIRE
PPL/GRY WIRE
PPL/LT BLU WIRE
PPL/LT GRN WIRE
PPL/PNK WIRE
PPL/RED WIRE
PPL/VIO WIRE
PPL/YEL WIRE
RED WIRE
RGND
RIGHT SPOT LIGHT ASSEMBLY (EXCEPT HYBRID W/ PANORAMIC ROOF)
RIGHT VANITY LIGHT ASSEMBLY
RIGHT VANITY MIRROR ASSEMBLY
RIGHT VISOR ASSEMBLY
RILL
RLDS
RLMP
RLSW
RLVS
RLVT
RRDS
RRMP
RRSW
RRVS
RRVT
SPOT LIGHT ASSEMBLY
VIO WIRE
W/ PANORAMIC ROOF
W/O PANORAMIC ROOF
WHT WIRE
WHT/BLK WIRE
Go to component -> Courtesy lamps circuit (4 of 4) -> RIGHT VANITY MIRROR ASSEMBLY
