Lexus LS V (2017-2021) non-contact switch Wiring diagrams
This page contains all the electrical diagrams for the component. non-contact switch, in which he is found in the car Lexus LS V (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
non-contact switch wiring diagram (1 of 4)
A/BAG FUSE
ACL PNK RBR- WIRE
BLK WIRE
BLU WIRE
CAN I/F
COMBINATION METER ASSEMBLY
COMPUTER DATA LINES SYSTEM
DISPLAY DRIVER
DRIVER SIDE J/B
GA GD
GB (DRIVER DOOR SILL)
GRN WIRE
LBR-
LED DRIVER
LEFT PEDESTRIAN DETECTION CHAMBER ASSEMBLY
LEFT POP UP HOOD LIFTER ASSEMBLY
LEFT POP UP HOOD LIFTER ASSEMBLY 2
LEFT REAR SEAT INNER BELT ASSEMBLY
NON-CONTACT SWITCH
PASSENGER SIDE J/B
PEDESTRIAN DETECTION ECU ASSEMBLY
PFL
PFR
PLL-
PLR+
PNK CANH WIRE
PNK WIRE
PPL
PPL/GRN WIRE
PSL+
PSR
PTL-
PTR+
PUL-
PUR
RBR-
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT PEDESTRIAN DETECTION CHAMBER ASSEMBLY
RIGHT POP UP HOOD LIFTER ASSEMBLY
RIGHT POP UP HOOD LIFTER ASSEMBLY 2
RIGHT REAR SEAT INNER BELT ASSEMBLY
TELLTALES
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Active bodyworks circuit -> NON-CONTACT SWITCH
non-contact switch wiring diagram (2 of 4)
A/BAG FUSE
AIR BAG ECU ASSEMBLY
BELT WARNING OCCUPANT DETECTION SENSOR (LEFT REAR SEAT)
BGND
BLK WIRE
BLU WIRE
BRN WIRE
BSW
COMPUTER DATA LINES SYSTEM
CTY
DIODE
GRN WIRE
GRY WIRE
LB (RIGHT REAR DOOR)
LBR-
LD (LEFT "C" PILLAR)
LEFT FRONT DOOR COURTESY LIGHT SWITCH ASSEMBLY
LEFT FRONT OCCUPANT CLASSIFICATION SENSOR
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT REAR OCCUPANT CLASSIFICATION SENSOR
LEFT REAR POSITION CONTROL ECU ASSEMBLY
LEFT REAR SEAT INNER BELT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MAIN BODY ECU (LEFT END OF DASH)
NON-CONTACT
NON-CONTACT SWITCH
OCCUPANT DETECTION ECU
ODS
ORG/ WIRE
PASSENGER SIDE J/B
PASSIVE RESTRAINTS SYSTEM
PNK WIRE
PPL
PPL LBR-
PPL/PNK WIRE
PPL/RED WIRE
RBE+
RED WIRE
RELAY ENERGIZED
RIGHT END OF DASH)
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SKID CONTROL ECU ASSEMBLY
SWITCH
VIO WIRE
W/ DIODE
W/ REAR POWER SEAT
W/O DIODE
W/O REAR POWER SEAT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Seat belt warning circuit (1 of 2) -> NON-CONTACT SWITCH
non-contact switch wiring diagram (3 of 4)
BLK WIRE
BRN WIRE
DRIVER SIDE J/B
DRIVER SIDE SQUIB CIRCUIT (HORN BUTTON ASSEMBLY)
GRN WIRE
GSW
ICL-
LBE- LSP-
LEFT CURTAIN SHIELD AIR BAG ASSEMBLY
LEFT FRONT SEAT AIR BAG ASSEMBLY
LEFT FRONT SEAT INNER BELT ASSEMBLY
LEFT REAR SEAT AIR BAG ASSEMBLY
LEFT REAR SEAT CUSHION AIR BAG ASSEMBLY
LEFT SEAT BELT PRETENSIONER (LEFT FRONT SEAT OUTER BELT ASSEMBLY)
LEFT SEAT POSITION AIR BAG SENSOR
LSP +
MAIN BODY ECU
NCA WIRE
NON-CONTACT SWITCH
RED WIRE
RIGHT FRONT AIR BAG SENSOR
SFL-
SPIRAL CABLE W/ SENSOR SUB-ASSEMBLY
SR-
SRL-
TELEMATICS TRANSCEIVER ASSEMBLY
WHT WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (2 of 4) -> NON-CONTACT SWITCH
non-contact switch wiring diagram (4 of 4)
BBR+
BCR+
BDR
BDR+ BBR-
BGND
BLK WIRE
BLU WIRE
BRN WIRE
BSW
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
LEFT FRONT AIR BAG SENSOR
LEFT FRONT OCCUPANT CLASSIFICATION SENSOR
LEFT REAR OCCUPANT CLASSIFICATION SENSOR
LEFT SEAT BELT PRETENSIONER (LEFT REAR SEAT OUTER BELT ASSEMBLY 1)
LT GRN WIRE
NON-CONTACT SWITCH
OCCUPANT DETECTION ECU
PNK WIRE
RBE+
RED WIRE
RIGHT DOOR SIDE AIR BAG SENSOR
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT REAR AIR BAG SENSOR ASSEMBLY
RIGHT REAR DOOR
RIGHT REAR SEAT AIR BAG ASSEMBLY
RIGHT SIDE AIR BAG SENSOR ASSEMBLY 2
SIG (1)
SIG 3
SL-
SRR+
SVC 1
SVC 3
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
Go to component -> Supplemental restraint circuit (3 of 4) -> NON-CONTACT SWITCH
