Lexus LS V (2017-2021) left rear lumber support pump sub-assembly Wiring diagram
This page shows the only wiring diagram for the component.left rear lumber support pump sub-assembly, which is found in the car Lexus LS V (2017-2021). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear lumber support pump sub-assembly (1 of 1)
BDR
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
EXCEPT HYBRID
FRV-
GRN WIRE
GRY WIRE
IND
LA (LEFT REAR DOOR)
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT REAR LUMBER SUPPORT PUMP SUB-ASSEMBLY
LEFT REAR POSITION CONTROL ECU ASSEMBLY
LEFT REAR POWER SEAT SLIDE MOTOR (REAR SEAT ADJUSTER ASSEMBLY 2)
LEFT REAR POWER SEAT TILT MOTOR (REAR SEAT ADJUSTER ASSEMBLY 2)
LEFT REAR SEAT BACK HEATER ASSEMBLY
LEFT SEAT MEMORY SWITCH
LT GRN WIRE
MMRY
MSWE
ORG/ WIRE
PNK WIRE
PPL/BRN WIRE
PPL/RED WIRE
REAR CONSOLE BOX WIRE
REAR SEAT HEADREST ADJUSTER SUB-ASSEMBLY 2
RED WIRE
SLD
VIO WIRE
W/ REAR POWER SEAT
WHT WIRE
WHT/BLK WIRE
Go to component -> Memory rear seat circuit (2 of 5) -> LEFT REAR LUMBER SUPPORT PUMP SUB-ASSEMBLY
