Lexus LS V (2017-2021) height control valve sub- assembly 2 Wiring diagrams
This page contains all the electrical diagrams for the component. height control valve sub- assembly 2, in which he is found in the car Lexus LS V (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram height control valve sub- assembly 2 (1 of 3)
AIRSUS 1 FUSE
AIRSUS RELAY
BLK WIRE
BLU WIRE
BRN WIRE
FRONT HEIGHT CONTROL PRESSURE SENSOR
GRY WIRE
HEIGHT CONTROL COMPRESSOR 1
HEIGHT CONTROL COMPRESSOR THERMISTOR ASSEMBLY
HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
HOT AT ALL TIMES
LF (RIGHT "C" PILLAR)
LH -
LT GRN WIRE
LUGGAGE ROOM R/B 2
PNK WIRE
RED WIRE
RH-
RM+
SBL
SHB
SHG
TOIL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Adaptive variable suspension circuit (3 of 4) -> HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
Wiring diagram height control valve sub- assembly 2 (2 of 3)
BELT WARNING OCCUPANT DETECTION SENSOR (RIGHT REAR SEAT)
BLK WIRE
BLU WIRE
CAN JUNCTION TERMINAL 1
CAN JUNCTION TERMINAL 6
CLEARANCE WARNING ECU ASSEMBLY
DOOR CONTROL SWITCH
DOOR UNLOCK SWITCH (LUGGAGE COMPARTMENT DOOR LOCK CYLINDER ASSEMBLY)
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
GRN WIRE
HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
KICK DOOR CONTROL SENSOR
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
MULTI-DISPLAY CONTROLLER SUB-ASSEMBLY
PNEUMATIC VALVE CONTROL ECU (RIGHT REAR SEAT) (REFRESH)
PNEUMATIC VALVE CONTROL ECU (RIGHT REAR SEAT) (SUPPORT)
PPL
RIGHT AUTO CURTAIN CONTROL RELAY (RIGHT REAR SIDE WINDOW CURTAIN ASSEMBLY)
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR POSITION CONTROL ECU ASSEMBLY
RIGHT REAR SEAT BACK HEATER ASSEMBLY
RIGHT REAR SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
RIGHT REAR SEAT HEATER ASSEMBLY
RIGHT REAR SEAT INNER BELT ASSEMBLY
RIGHT REAR SEAT INNER BELT W/ CENTER ASSEMBLY
RIGHT REAR SKID CONTROL SENSOR WIRE
STEREO COMPONENT AMPLIFIER ASSEMBLY
STEREO COMPONENT EQUALIZER ASSEMBLY
SUSPENSION CONTROL ECU
VIO WIRE
W/ REAR POWER SEAT
W/O DIODE
W/O REAR POWER SEAT
WHT/BLK WIRE
Go to component -> Ground distribution circuit (9 of 10) -> HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
Wiring diagram height control valve sub- assembly 2 (3 of 3)
BELT WARNING OCCUPANT DETECTION SENSOR (RIGHT REAR SEAT)
BLK WIRE
BLU WIRE
CAN JUNCTION TERMINAL 1
CAN JUNCTION TERMINAL 6
CLEARANCE WARNING ECU ASSEMBLY
DOOR UNLOCK SWITCH (LUGGAGE COMPARTMENT DOOR LOCK CYLINDER ASSEMBLY)
ELECTRICAL KEY, TIRE PRESSURE MONITORING SYSTEM RECEIVER ASSEMBLY
GRN WIRE
HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
KICK DOOR CONTROL SENSOR
LEFT LICENSE PLATE LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
MULTI-DISPLAY CONTROLLER SUB-ASSEMBLY
PNEUMATIC VALVE CONTROL ECU (RIGHT REAR SEAT) (REFRESH)
PNEUMATIC VALVE CONTROL ECU (RIGHT REAR SEAT) (SUPPORT)
PPL
RIGHT AUTO CURTAIN CONTROL RELAY (RIGHT REAR SIDE WINDOW CURTAIN ASSEMBLY)
RIGHT BLIND SPOT MONITOR SENSOR
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR POSITION CONTROL ECU ASSEMBLY
RIGHT REAR SEAT BACK HEATER ASSEMBLY
RIGHT REAR SEAT CUSHION CLIMATE CONTROL BLOWER ASSEMBLY
RIGHT REAR SEAT HEATER ASSEMBLY
RIGHT REAR SEAT INNER BELT ASSEMBLY
RIGHT REAR SEAT INNER BELT W/ CENTER ASSEMBLY
RIGHT REAR SKID CONTROL SENSOR WIRE
STEREO COMPONENT AMPLIFIER ASSEMBLY
STEREO COMPONENT EQUALIZER ASSEMBLY
SUSPENSION CONTROL ECU
VIO WIRE
W/ REAR POWER SEAT
W/ VIBRATION SEAT SYSTEM
W/O REAR POWER SEAT
WHT/BLK WIRE
Go to component -> Ground distribution circuit (9 of 9) -> HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
