Lexus LS V (2017-2021) height control compressor 1 Wiring diagrams
This page contains all the electrical diagrams for the component. height control compressor 1, in which he is found in the car Lexus LS V (2017-2021). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
height control compressor 1 wiring diagram (1 of 3)
AIRSUS 1 FUSE
AIRSUS RELAY
BLK WIRE
BLU WIRE
BRN WIRE
FRONT HEIGHT CONTROL PRESSURE SENSOR
GRY WIRE
HEIGHT CONTROL COMPRESSOR 1
HEIGHT CONTROL COMPRESSOR THERMISTOR ASSEMBLY
HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
HOT AT ALL TIMES
LF (RIGHT "C" PILLAR)
LH -
LT GRN WIRE
LUGGAGE ROOM R/B 2
PNK WIRE
RED WIRE
RH-
RM+
SBL
SHB
SHG
TOIL
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Adaptive variable suspension circuit (3 of 4) -> HEIGHT CONTROL COMPRESSOR 1
height control compressor 1 wiring diagram (2 of 3)
A/F HTR RELAY
AIRSUS RELAY
BATT FAN 1 RELAY
BATTERY
BLK WIRE
BLK/YEL WIRE
BRAKE CONTROL POWER SUPPLY W/ BRACKET ASSEMBLY
BRN WIRE
EFI MAIN 2 RELAY
EFI- MAIN 1 RELAY
ENGINE ROOM R/B 1
HEIGHT CONTROL COMPRESSOR 1
IGCT 1 RELAY
INV RELAY
INV W/ PMP RELAY
INVERTER WATER PUMP ASSEMBLY (W/ MOTOR)
LEFT BLIND SPOT MONITOR SENSOR
LEFT REAR COMBINATION LIGHT ASSEMBLY
LUG- ACC RELAY
LUGGAGE ROOM J/B 1
OIL PMP RELAY
QUICK HEATER ASSEMBLY
RIGHT REAR COMBINATION LIGHT ASSEMBLY
SEMICONDUCTOR POWER INTEGRATION ECU 1
SUB-BATTERY W/ CONTROL ASSEMBLY
VOLTAGE INVERTER ASSEMBLY
WHT/BLK WIRE
WINDSHIELD WASHER MOTOR, PUMP ASSEMBLY
WIPER 1 RELAY
Go to component -> Ground distribution circuit (3 of 10) -> HEIGHT CONTROL COMPRESSOR 1
height control compressor 1 wiring diagram (3 of 3)
AIRSUS RELAY
BATTERY
BLK/YEL WIRE
DA (AWD) DB
EFI MAIN 2 RELAY
HEIGHT CONTROL COMPRESSOR 1
IGNITION COIL ASSEMBLY 1
IGNITION COIL ASSEMBLY 2
IGNITION COIL ASSEMBLY 3
IGNITION COIL ASSEMBLY 4
IGNITION COIL ASSEMBLY 5
IGNITION COIL ASSEMBLY 6
INV RELAY
LEFT CAM TIMING OIL CONTROL MOTOR W/ EDU ASSEMBLY
LUG- ACC RELAY
LUGGAGE ROOM J/B 1
REAR ACTIVE STABILIZER CONTROL ECU
REAR STEERING CONTROL ECU
RIGHT CAM TIMING OIL CONTROL MOTOR W/ EDU ASSEMBLY
SUB-BATTERY W/ CONTROL ASSEMBLY
VOLTAGE INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (3 of 9) -> HEIGHT CONTROL COMPRESSOR 1
