Heated mirrors circuit for Lexus LS IV (2006-2012)
Heated mirrors circuit
21 22 CANH CANL
BLK WIRE
BLU WIRE
CANN CANP GND
COMPUTER DATA LINES SYSTEM
D DOOR 2 FUSE
DISPLAY, NAVIGATION MODULE DISPLAY
DRIVER SIDE J/B (LEFT END OF DASH)
HOT AT ALL TIMES
HOT AT ALL TIMES PASSENGER SIDE J/B P DOOR 2 (RIGHT END FUSE OF DASH)
HTR
LEFT FRONT MULTIPLEX NETWORK DOOR ECU (DRIVER'S DOOR)
LEFT OUTER REAR VIEW MIRROR (AT MIRROR)
MIRROR HEATER
REAR WINDOW DEFOGGER SWITCH
RED WIRE
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU (FRONT PASSENGER'S DOOR)
RIGHT OUTER REAR VIEW MIRROR (AT MIRROR)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
