Lexus LS IV (2006-2012) window driver lock side switch auto switch Wiring diagram
This page shows the only wiring diagram for the component.window driver lock side switch auto switch, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram window driver lock side switch auto switch (1 of 1)
6 5 4 3 2 GND RSSI ASEL DATA +5
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CERTIFICATION ECU (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
CONTROL CIRCUIT
D RR DOOR FUSE
DCTY
DOOR CONTROL RECEIVER (RIGHT REAR OF LUGGAGE COMPT)
DRIVER DRIVER SIDE DOWN SWITCH SIDE UP SWITCH
DRIVER SIDE J/B (LEFT END OF DASH)
FRONT PASSENGER SIDE CONTROL SWITCH
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/B 3 (RIGHT SIDE OF DASH)
J/B 4 (RIGHT SIDE OF DASH)
LED
LEFT FRONT DOOR COURTESY SWITCH (LEFT "B" PILLAR)
LEFT FRONT POWER WINDOW REGULATOR MOTOR (DRIVER'S DOOR)
LEFT REAR SIDE CONTROL SWITCH
LIN
MAIN BODY ECU (LEFT END OF DASH)
ORG/ WIRE
POWER WINDOW REGULATOR MASTER SWITCH
RDA ASEL RSSI CANH CANL
RED WIRE
RIGHT REAR SIDE CONTROL
SWITCH
WHT WIRE
WHT/BLK WIRE
WINDOW DRIVER LOCK SIDE SWITCH AUTO SWITCH
Go to component -> Power windows circuit (2 of 3) -> WINDOW DRIVER LOCK SIDE SWITCH AUTO SWITCH
