Lexus LS IV (2006-2012) voltage inverter assembly Wiring diagrams
This page contains all the electrical diagrams for the component. voltage inverter assembly, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram voltage inverter assembly (1 of 2)
11 11 10 10 W/ CONSOLE W/ ROOF
BACK
BATTERY COOLING BLOWER ASSEMBLY
BLK WIRE
BRN WIRE
COOLING BOX ASSEMBLY (4-SEATER)
DISC PLAYER ASSEMBLY
DISC PLAYER ASSEMBLY, HEADPHONE TERMINAL
FROM
FROM J/C
FUEL LID COURTESY SWITCH
INV RELAY
J/C
LEFT LUGGAGE REAR ELECTRICAL LIGHT KEY ASSEMBLY SWITCH
LEFT REAR ABSORBER CONTROL ACTUATOR
LUGGAGE COMPARTMENT DOOR LOCK CYLINDER
LUGGAGE DOOR CLOSER ASSEMBLY
LUGGAGE ROOM J/B (LEFT SIDE OF LUGGAGE COMPT)
OBJECT RECOGNITION BATTERY ECU COOLING SHIELD BLOWER ASSEMBLY 2
OTTOMAN RECLINING SENSOR (IF EQUIPPED)
POWER STEERING CONVERTER ASSEMBLY
POWER TRUNK LID CONTROL SWITCH
REAR HEIGHT CONTROL VALVE SUB- ASSEMBLY 2
REAR JUNCTION BLOCK ECU
RELAY
RIGHT REAR ABSORBER CONTROL ACTUATOR
RIGHT REAR LEFT REAR COMBINATION COMBINATION LIGHT LIGHT ASSEMBLY ASSEMBLY
RIGHT REAR LIGHT ASSEMBLY
RIGHT REAR MULTIPLEX NETWORK DOOR ECU
RIGHT REAR POWER SEAT CONTROL ECU ASSEMBLY
RIGHT REAR POWER SEAT MOTOR ASSEMBLY
RIGHT REAR SEAT
RIGHT REAR SEAT CLIMATE CONTROL ECU
RIGHT REAR SEAT HEADREST ADJUSTER SUB ASSEMBLY 1
RR-ACC RELAY
SEAT VIBRATION ECU
SEAT VIBRATOR SWITCH
STEREO COMPONENT AMPLIFIER
TELEVISION DISPLAY ASSEMBLY
TELEVISION SWITCH, VOLUME ASSEMBLY
TO J/C
VOLTAGE INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Ground distribution circuit (6 of 7) -> VOLTAGE INVERTER ASSEMBLY
Wiring diagram voltage inverter assembly (2 of 2)
1 2 3 4 5 6 7 8 IG
BLK WIRE
BLU WIRE
ECU-IG FUSE
ENGINE CONTROLS SYSTEM
FROM
FROM LUGGAGE ROOM J/B (DIAGRAM 4 OF 6)
FROM RR ACC RELAY AC (DIAGRAM 4 OF 6) FUSE
IGN FUSE
INJ FUSE
INV RELAY
JUNCTION
LT BLU WIRE
LUGGAGE ROOM J/B (LEFT SIDE OF LUGGAGE COMPT)
MAIN BODY ECU
NAVIGATION, SUPPLEMENTAL RESTRAINTS SYSTEMS
P-J/B FUSE
PNK WIRE
POWER OUTLET
RED WIRE
RELAY
VIO WIRE
VOLTAGE INVERTER ASSEMBLY
W/ 5 SEATER, OTTOMAN W/O 5 SEATER, OTTOMAN
WHT WIRE
WHT/BLK WIRE
Go to component -> Power distribution circuit (6 of 6) -> VOLTAGE INVERTER ASSEMBLY
