Lexus LS IV (2006-2012) stereo component amplifier assembly (right rear of Wiring diagram
This page shows the only wiring diagram for the component.stereo component amplifier assembly (right rear of, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram stereo component amplifier assembly (right rear of (1 of 1)
-TW
1 2 3 4 5 6 +B GND
11 12 SLDO MO-
6 7 8 9 MO+
AMP FUSE
BLK WIRE
BLU WIRE
CENTER SPEAKER
CTR+ WFL+
D MPX-B 2 FUSE
DRIVER SIDE J/B (LEFT END OF DASH)
GRY WIRE
HOT AT ALL TIMES
LEFT FRONT TWEETER
LEFT FRONT WOOFER
LEFT REAR SQUAWKER
LEFT REAR TWEETER
LT BLU WIRE
LT GRN WIRE
LUGGAGE COMPT)
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK CTR+ WFL+ WIRE
PNK WIRE
RED WIRE
RIGHT FRONT WOOFER
RIGHT REAR SQUAWKER
RIGHT REAR TWEETER
RLD
RRD
STEREO COMPONENT AMPLIFIER ASSEMBLY (RIGHT REAR OF
VIO WIRE
WFR+ FL+ TWL+ TWR+ WFR- FL- FR- FR+ TWL- TWR-
WHT WIRE
WHT/BLK WIRE
WOOFER
WUO
YEL WIRE
Go to component -> Rear seat entertainment circuit, with roof type & without multi display (4 of 4) -> STEREO COMPONENT AMPLIFIER ASSEMBLY (RIGHT REAR OF
