Lexus LS IV (2006-2012) spiral cable sub assembly (in steering Wiring diagram
This page shows the only wiring diagram for the component.spiral cable sub assembly (in steering, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram spiral cable sub assembly (in steering (1 of 1)
2 3 CANP CANN
27 28 CANH CANL
5 14 CANP CANN
9 10 CANN CANP
BLK WIRE
BLU WIRE
CANL CANH
CANN
CANP
CERTIFICATION ECU ASSEMBLY (BEHIND LEFT
COLUMN)
COMBINATION METER
CT+
DLC 3 (LEFT SIDE OF DASH)
END OF DASH)
GRN WIRE
MULTIPLEX TILT, TELESCOPIC ECU (ON STEERING COLUMN)
OUTER MIRROR SWITCH ASSEMBLY
PNK CANP CANN WIRE
PNK WIRE
REAR ACTIVE STABILIZER CONTROL ECU ASSEMBLY (LEFT REAR QUARTER PANEL)
RED WIRE
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU (FRONT PASSENGER'S DOOR)
SPIRAL CABLE SUB ASSEMBLY (IN STEERING
STEERING SENSOR (IN STEERING COLUMN)
VIO WIRE
W/ ACTIVE STABILIZER SUSPENSION SYSTEM
W/O ACTIVE STABILIZER SUSPENSION SYSTEM
WHT WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YAW RATE SENSOR (UNDER CENTER FLOOR CONSOLE)
YEL WIRE
Go to component -> Body control modules circuit (2 of 3) -> SPIRAL CABLE SUB ASSEMBLY (IN STEERING
