Lexus LS IV (2006-2012) right vvt relay Wiring diagram
This page shows the only wiring diagram for the component.right vvt relay, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right vvt relay (1 of 1)
5 6 CANH CANL
A/F FUSE
A/F RELAY
BLK WIRE
BLU WIRE
BRN WIRE
COMPT)
COMPUTER DATA LINES SYSTEM
EFI FUSE
EFI-B FUSE
EMV-
ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT)
EXHAUST GAS TEMPERATURE SENSOR (BANK 1)
EXHAUST GAS TEMPERATURE SENSOR (BANK 2)
FUEL RELIEF VALVE ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
FUEL TANK PRESSURE SENSOR (AT FUEL TANK ASSEMBLY)
FUSE
GRN WIRE
LEFT VVT RELAY
MAIN BODY ECU (LEFT END OF DASH)
NCA WIRE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
PTNK
RED WIRE
RELIEF VLV FUSE
RELIEF VLV RELAY
RIGHT VVT RELAY
SKSW
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.0l, engine controls circuit (2 of 7) -> RIGHT VVT RELAY
