Lexus LS IV (2006-2012) right rear speaker assembly Wiring diagrams
This page contains all the electrical diagrams for the component. right rear speaker assembly, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram right rear speaker assembly (1 of 2)
-TW
1 2 3 4 5 6 +B GND
1 2 3 4 5 6 7 8 9 10 SL+ SR+ RL+ RR+ SL- SR-
AMP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CTR- CTR+
DRIVER SIDE J/B (LEFT END OF DASH)
FL+ FR+
FLOOR STEREO COMPONENT SPEAKER ASSEMBLY
FRONT SPEAKER ASSEMBLY 3
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER ASSEMBLY 1
LEFT REAR HEADER SPEAKER ASSEMBLY
LEFT REAR SPEAKER ASSEMBLY
LEFT REAR SPEAKER ASSEMBLY 2
LEFT REAR SPEAKER ASSEMBLY 3
LT BLU WIRE
LT GRN WIRE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RED WIRE
RIGHT FRONT SPEAKER ASSEMBLY 1
RIGHT REAR HEADER SPEAKER ASSEMBLY
RIGHT REAR SPEAKER ASSEMBLY
RIGHT REAR SPEAKER ASSEMBLY 2
RIGHT REAR SPEAKER ASSEMBLY 3
RL RR
RLD
RRD
SPD WUI MI+ SLDI MO+
STEREO COMPONENT AMPLIFIER ASSEMBLY (RIGHT REAR OF LUGGAGE COMPT)
TWL+ TWR+ WFL+
VIO WIRE
WF-
WFR+ TWL- TWR-
WFR-
WHT WIRE
WHT/BLK WIRE
WUO MI- SLDO MO-
YEL WIRE
Go to component -> Rear seat entertainment circuit, with console type (4 of 4) -> RIGHT REAR SPEAKER ASSEMBLY
Wiring diagram right rear speaker assembly (2 of 2)
-TW
1 2 3 4 5 6 +B GND
1 2 3 4 5 6 7 8 9 10 SL+ SR+ RL+ RR+ SL- SR-
AMP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CTR- CTR+
DRIVER SIDE J/B (LEFT END OF DASH)
FL+ FR+
FLOOR STEREO COMPONENT SPEAKER ASSEMBLY
FRONT SPEAKER ASSEMBLY 3
GRY WIRE
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER ASSEMBLY 1
LEFT REAR HEADER SPEAKER ASSEMBLY
LEFT REAR SPEAKER ASSEMBLY
LEFT REAR SPEAKER ASSEMBLY 2
LEFT REAR SPEAKER ASSEMBLY 3
LT BLU WIRE
LT GRN WIRE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RED WIRE
RIGHT FRONT SPEAKER ASSEMBLY 1
RIGHT REAR HEADER SPEAKER ASSEMBLY
RIGHT REAR SPEAKER ASSEMBLY
RIGHT REAR SPEAKER ASSEMBLY 2
RIGHT REAR SPEAKER ASSEMBLY 3
RL RR
RLD
RRD
SPD WUI MI+ SLDI MO+
STEREO COMPONENT AMPLIFIER ASSEMBLY (RIGHT REAR OF LUGGAGE COMPT)
TWL+ TWR+ WFL+
VIO WIRE
WF-
WFR+ TWL- TWR-
WFR-
WHT WIRE
WHT/BLK WIRE
WUO MI- SLDO MO-
YEL WIRE
Go to component -> Rear seat entertainment circuit, with roof type (4 of 4) -> RIGHT REAR SPEAKER ASSEMBLY
