Lexus LS IV (2006-2012) right lower 1 instrument panel air bag assembly Wiring diagram
This page shows the only wiring diagram for the component.right lower 1 instrument panel air bag assembly, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right lower 1 instrument panel air bag assembly (1 of 1)
27 28 29 30 -SR -SL +SR +SL
ABFS
AHL+
AIR
AIR BAG ECU ASSEMBLY
ARON
BBL+
BBL- BBL+
BCL+
BLK WIRE
BRN WIRE
CANL PAON
COMPUTER DATA LINES SYSTEM
DISPLAY, NAVIGATION MODULE DIPLAY PASSENGER AIR BAG ON/OFF INDICATOR
DK DK
ENGINE ROOM J/B 2 (RIGHT SIDE
FRONT PASSENGER SIDE SQUIB CIRCUIT SECOND STEP
HOT IN ON OR START
IGN FUSE
LEFT CURTAIN SHIELD AIR BAG SQUIB ASSEMBLY (LEFT SIDE OF ROOF)
LEFT FRONT PRETENSIONER (BASE OF LEFT "B" PILLAR)
LEFT FRONT SIDE AIR BAG SQUIB CIRCUIT (UNDER DRIVER'S SEAT)
LEFT LOWER 1 INSTRUMENT PANEL AIR BAG ASSEMBLY
LEFT REAR AIR BAG SENSOR (LEFT "C" PILLAR)
LEFT REAR PRETENSIONER (LEFT "C" PILLAR)
LEFT REAR SIDE AIR BAG ASSEMBLY (LEFT REAR SEAT BACK)
LEFT SIDE AIR BAG SENSOR ASSEMBLY (BASE OF LEFT "B" PILLAR)
OF ENGINE COMP)
P- P+ D+ D-
P-AB GSW PK+ PK-
PASSENGER SIDE J/B (RIGHT END OF DASH)
RED WIRE
RIGHT LOWER 1 INSTRUMENT PANEL AIR BAG ASSEMBLY
RL- RL+
SEAT POSITION AIR BAG SENSOR
SPIRAL CABLE SUB-ASSEMBLY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (1 of 2) -> RIGHT LOWER 1 INSTRUMENT PANEL AIR BAG ASSEMBLY
