Lexus LS IV (2006-2012) right active headrest airbag squib circuit (front passenger's Wiring diagram
This page shows the only wiring diagram for the component.right active headrest airbag squib circuit (front passenger's, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram right active headrest airbag squib circuit (front passenger's (1 of 1)
1 2 AHR+ AHR-
3 1 2 GPS VPS PS
AIR BAG ECU ASSEMBLY (UNDER CENTER FLOOR CONSOLE)
BBR+
BCR+
BLK WIRE
BLU WIRE
BRN WIRE
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DATA LINK CONNECTOR 3
DRIVER MAIN SIDE J/B BODY ECU (LEFT END OF DASH)
ENGINE ROOM J/B 2 (RIGHT
FSR+ BBR+ BBR-
FUSE
GND PS VPS GBT IG DIA FSR+ FSR- BSW BGND GPS BT VBT PNK WIRE
GRN WIRE
GRY WIRE
GSW
HOT IN ON OR START
J/B 3
MICRO COMPUTER
OCCUPANT DETECTION ECU
OCCUPANT DETECTION SENSOR
P RR-
P-J/B FUSE
PASSENGER SIDE J/B
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RED WIRE
RIGHT ACTIVE HEADREST AIRBAG SQUIB CIRCUIT (FRONT PASSENGER'S
RIGHT CURTAIN SHIELD AIR BAG ASSEMBLY (RIGHT SIDE OF ROOF)
RIGHT END OF DASH)
RIGHT FRONT SEAT INNER BELT ASSEMBLY
RIGHT FRONT SIDE AIR BAG SQUIB CIRCUIT (UNDER FRONT PASSENGER'S SEAT)
RIGHT REAR RIGHT SIDE AIR BAG AIR BAG SENSOR ASSEMBLY SENSOR (RIGHT "C" PILLAR)
RIGHT REAR SEAT AIR BAG ASSEMBLY (W/ OTTOMAN)
RIGHT REAR SIDE AIR BAG ASSEMBLY (BASE OF RIGHT "B" PILLAR)
SEAT BACK)
SEAT BELT TENSION SENSOR
SIDE OF ENGINE COMPT)
SIL
SL-
SR-
SRS IND
SUPPLY POWER
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
YEL/BLK WIRE
YEL/GRN WIRE
YEL/RED WIRE
Go to component -> Supplemental restraint circuit (2 of 2) -> RIGHT ACTIVE HEADREST AIRBAG SQUIB CIRCUIT (FRONT PASSENGER'S
