Lexus LS IV (2006-2012) +res on- -set off Wiring diagram
This page shows the only wiring diagram for the component.+res on- -set off, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram +res on- -set off (1 of 1)
+BM
+RES ON- -SET OFF
13 8 12 STP IGSW
15 9 10 13 14 CCS CAN- CAN+ CANL CANH
28 18 CAN- CAN+
29 20 23 28 21 22 VPA EPA VCPA
7 3 BATT MREL PNK WIRE
ACCELERATOR POSITION SENSOR (LEFT SIDE OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C/OPN RELAY
COMPUTER DATA LINE SYSTEM
CRUISE CONTROL MAIN SWITCH
DRIVER SIDE J/B (LEFT END OF DASH)
ECU-IG FUSE
EFI
EFI MAIN EFI FUSE MAIN RELAY
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT)
ETA M+ M-
ETCS FUSE
FUSE
GRN WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START E/G RM-
J/B 5 (LEFT SIDE OF DASH)
NCA WIRE
ORG/ WIRE
PNK WIRE
RED WIRE
RELAY
SPIRAL CABLE (IN STEERING COLUMN)
TRANSMISSIONS SYSTEM
VIO WIRE
VTA VCTA
W/ VEHICLE DYNAMICS INTEGRATED MANAGEMENT
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Cruise control circuit, without dynamic radar controls (1 of 2) -> +RES ON- -SET OFF
