Lexus LS IV (2006-2012) rear console switch shield Wiring diagram
This page shows the only wiring diagram for the component.rear console switch shield, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram rear console switch shield (1 of 1)
A/F RELAY
ABS FR MTR FOG RELAY RELAY ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY SHIELD
BRN WIRE
EFI MAIN RELAY
FAN
FRONT HEIGHT CONTROL VALVE
HEATER WATER PUMP ASSEMBLY
HEIGHT CONTROL COMPRESSOR MOTOR
HEIGHT CONTROL EXHAUST VALVE
IGCT IGCT RELAY RELAY
INVERTER WATER PUMP MOTOR ASSEMBLY
JUNCTION CONNECTOR SHIELD
LEFT BRAKE FRONT ACTUATOR SPEED ASSEMBLY SENSOR SHIELD SHIELD
MULTIPLEX NETWORK FRONT LIGHT ECU
MULTIPLEX NETWORK FRONT LIGHT ECU SHIELD
OIL PUMP RELAY
PANEL)
POWER STEERING ECU ASSEMBLY SHIELD
POWER TRUNK LID CONTROL ECU SHIELD
REAR ACTIVE STABILIZER CONTROL ECU ASSEMBLY SHIELD
REAR CONSOLE SWITCH SHIELD
REAR JUNCTION JUNCTION BLOCK CONNECTOR ECU SHIELD SHIELD
RED WIRE
RELAY ENGINE ROOM R/B 5 (RIGHT FRONT OF ENGINE COMPT)
RELAY RELAY
RIGHT FRONT ABSORBER CONTROL ACTUATOR
RIGHT FRONT SPEED SENSOR SHIELD
RIGHT LEFT H-LP LO H-LP LO RELAY RELAY
RIGHT REAR SPEED SENSOR SHIELD
SEAT BELT JUNCTION CONTROL CONNECTOR ECU SHIELD SHIELD
STEERING CONTROL ECU SHIELD
VVT LH RELAY
W/ CONVERTER INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 7) -> REAR CONSOLE SWITCH SHIELD
