Lexus LS IV (2006-2012) port fuel injector assembly 3 Wiring diagram

AIR FUEL RATIO SENSOR (BANK 1 SENSOR 1) (LEFT REAR OF ENGINE) AIR FUEL RATIO SENSOR (BANK 2 SENSOR 1) (RIGHT REAR OF ENGINE) BLK WIRE BLK/RED WIRE BLK/WHT WIRE BLU WIRE BLU/RED WIRE BLU/WHT WIRE BLU/YEL WIRE BRN WIRE CAM TIMING CONTROL W/ EDU MOTOR ASSEMBLY (BANK 2) (RIGHT FRONT OF ENGINE) CAM TIMING OIL CONTROL VALVE ASSEMBLY (BANK 1) CAMSHAFT POSITION SENSOR (FRONT OF RIGHT CYLINDER HEAD) ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT) FPD + GRN WIRE GRN/BLK WIRE GRN/RED WIRE GRN/WHT WIRE GRN/YEL WIRE GRY WIRE LT GRN WIRE M- M+ 80 60 40 20 NCA WIRE PNK ASM- ASM+ WIRE PNK WIRE PNK/BLU WIRE PORT FUEL INJECTOR ASSEMBLY 1 PORT FUEL INJECTOR ASSEMBLY 3 PORT FUEL INJECTOR ASSEMBLY 5 PORT FUEL INJECTOR ASSEMBLY 7 RED WIRE RED/BLU WIRE SGND THROTTLE BODY ASSEMBLY (ON THROTTLE BODY) VCTA ETA VIO WIRE VVL+ VVR+ VVT SENSOR (BANK 1 INTAKE SIDE) (LEFT SIDE OF ENGINE) WHT WIRE WHT/BLK WIRE WHT/RED WIRE YEL WIRE YEL/BLK WIRE
