Lexus LS IV (2006-2012) pnk mrel irel fc fpr batt igsw Wiring diagram
This page shows the only wiring diagram for the component.pnk mrel irel fc fpr batt igsw, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram pnk mrel irel fc fpr batt igsw (1 of 1)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
C/OPN RELAY
CANL CANH TACH
COMPUTER DATA LINES SYSTEM
DSVR
EFI EFI MAIN MAIN 2 FUSE FUSE
EFI MAIN 2 RELAY
EFI MAIN RELAY
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM R/B 2 (RIGHT
F/PMP RELAY
FUO FUEL
GRN WIRE
GRY WIRE
HEATED OXYGEN SENSOR (BANK 1 SENSOR 2) (ON EXHAUST SYSTEM, BELOW VEHICLE)
HEATED OXYGEN SENSOR (BANK 2 SENSOR 2) (ON EXHAUST SYSTEM, BELOW VEHICLE)
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LT BLU WIRE
NCA WIRE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK LIDO CAN- CAN+ WIRE
PNK MREL IREL FC FPR BATT IGSW WIRE
PNK PNK KSW WIRE
PNK PTNK WIRE
PNK TC WIRE
PNK WIRE
RED WIRE
SIDE OF ENGINE COMPT)
TACH
TRUNK, TAILGATE, FUEL DOORS SYSTEM
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.0l, engine controls circuit (1 of 7) -> PNK MREL IREL FC FPR BATT IGSW WIRE
