Lexus LS IV (2006-2012) mrel igsw Wiring diagram
This page shows the only wiring diagram for the component.mrel igsw, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram mrel igsw (1 of 1)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 BATT+
AIR CONDITIONING SYSTEM
ANTI-THEFT SYSTEM
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRN WIRE
CAN+ CAN- SFTD SFTU
COMPUTER DATA LINES SYSTEM
CRUISE CONTROL SYSTEM
DCIM
ENGINE ROOM R/B 5 (RIGHT FRONT OF ENGINE COMPT)
FCTL
FUSIBLE LINK BLOCK ASSEMBLY 1 (RIGHT REAR OF ENGINE COMPT)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HYBRID VEHICLE CONTROL ECU (LEFT FRONT OF ENGINE COMPT)
IGCT 3 FUSE
ILK
IMI IMO
INTERLOCK SWITCH (RIGHT REAR OF VEHICLE CHASSIS)
LT BLU WIRE
LT GRN WIRE
LUGGAGE ROOM J/B (LEFT SIDE OF LUGGAGE COMPT)
MREL IGSW
NCA WIRE
NEI GI
OHG
OHU
OHV
OHW
OIGH
OIL PMP FUSE
OIL PMP RELAY
OIL PUMP MOTOR CONTROLLER (RIGHT FRONT OF ENGINE COMPT)
OPST
ORG/ WIRE
PNK TC WIRE
PNK THB WIRE
PNK WIRE
PSOK
RED WIRE
SENSOR
SIG
SMRP NODD VLO
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 5.0l, hybrid system circuit (1 of 7) -> MREL IGSW
