Lexus LS IV (2006-2012) light headlight assembly Wiring diagram
This page shows the only wiring diagram for the component.light headlight assembly, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram light headlight assembly (1 of 1)
1 2 3 4 5 6 7 8 IG LR LL
16 15 24 23 SIDR CRAR SIDL CRAL
BLK WIRE
BLK/YEL WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CANP CANN FMIG
CENTER JUNCTION BLOCK J/B 3 (RIGHT SIDE OF DASH)
CENTER JUNCTION BLOCK J/B 4 (RIGHT SIDE OF DASH)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
D MPX-B 1 FUSE
DIODE (TURN SIGNAL) (LEFT END OF DASH)
DRIVER SIDE J/B (LEFT END OF DASH)
E/G
ECU-B FUSE
ENERGIZED ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
FR CTRL ALT
FR CTRL BAT
FUSE
GRN WIRE
GRY WIRE
HAZ FUSE
HAZ TURN SIGNAL FLASHER ASSEMBLY (LEFT SIDE OF DASH)
HOT AT ALL TIMES
HOT AT ALL TIMES DRIVER SIDE J/B (LEFT END OF DASH) STOP FUSE
I/F POWER SUPPLY
J/C
LEFT OUTER REAR VIEW MIRROR (AT MIRROR)
LEFT TURN IND
LIGHT HEADLIGHT ASSEMBLY
LT BLU WIRE
LT GRN WIRE
MARKER
MASTER IND
MICRO COMPUTER
MPXB
MULTIPLEX NETWORK FRONT LIGHT ECU (RIGHT FRONT OF ENGINE COMPT)
P-J/B FUSE
PARKING
PNK BATB ALTB WIRE
PNK EL ER WIRE
PNK WIRE
RIGHT HEADLIGHT ASSEMBLY
RIGHT OUTER REAR VIEW MIRROR (AT MIRROR)
RIGHT TURN IND
STOP LIGHT SWITCH ASSEMBLY (LEFT SIDE OF DASH)
TAIL IND (CANADA)
TRN+
TRNI
TURN
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (2 of 3) -> LIGHT HEADLIGHT ASSEMBLY
