Lexus LS IV (2006-2012) license plate light assembly Wiring diagram
This page shows the only wiring diagram for the component.license plate light assembly, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram license plate light assembly (1 of 1)
BACKUP
BACKUP LAMPS CIRCUIT
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CENTER JUNCTION BLOCK J/B 3 (RIGHT SIDE OF DASH)
CENTER STOP LIGHT ASSEMBLY
COMPUTER DATA LINES SYSTEM
DRIVING SUPPORT ECU ASSEMBLY (LEFT KICK PANEL)
FUSE
GRN WIRE
HOT AT ALL TIMES
HYBRID VEHICLE CONTROL ECU (LEFT FRONT OF ENGINE COMPT)
LEFT REAR COMBINATION LIGHT ASSEMBLY
LEFT REAR LIGHT ASSEMBLY
LGLB
LICENSE PLATE LIGHT ASSEMBLY
LUGGAGE ROOM J/B (LEFT SIDE OF LUGGAGE COMPT)
MARKER
MPXB
ORG/ WIRE
RADIO SETTING CONDENSER (LEFT "C" PILLAR)
REAR JUNCTION BLOCK ECU
RED WIRE
RELAY ENERGIZED
RIGHT REAR COMBINATION LIGHT ASSEMBLY
RIGHT REAR LIGHT ASSEMBLY
RR MPX B 1 FUSE
RR MPX-B 2 FUSE
SHIFT LOCK CONTROL ECU (IN CENTER CONSOLE)
SKID CONTROL ECU ASSEMBLY (LEFT REAR OF ENGINE COMPT)
STOP
STOP LP 1 FUSE
STOP LP 2 FUSE
T/P
TAIL FUSE
TAIL/STOP
TURN
VIO WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Exterior lamps circuit (3 of 3) -> LICENSE PLATE LIGHT ASSEMBLY
