Lexus LS IV (2006-2012) left rear right rear speaker speaker assembly assembly Wiring diagrams
This page contains all the electrical diagrams for the component. left rear right rear speaker speaker assembly assembly, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram left rear right rear speaker speaker assembly assembly (1 of 2)
-TW
1 2 3 4 5 6 +B GND
1 2 3 4 5 6 7 8 9 10 SL+ SR+ RL+ RR+ SL- SR-
AMP FUSE
BLK WIRE
BLU WIRE
BRN WIRE
CTR- CTR+ FL- FR- PNK WIRE
D MPX-B 2 FUSE
DRIVER SIDE J/B (LEFT END OF DASH)
FL+ FR+
FLOOR STEREO COMPONENT SPEAKER ASSEMBLY
FRONT SPEAKER ASSEMBLY 3
GRN WIRE
GRY WIRE
HOOK OFF
HOT AT ALL TIMES
INSTRUMENT CLUSTER SYSTEM
LEFT FRONT SPEAKER ASSEMBLY 1
LEFT REAR HEADER SPEAKER ASSEMBLY
LEFT REAR RIGHT REAR SPEAKER SPEAKER ASSEMBLY ASSEMBLY
LEFT REAR SPEAKER ASSEMBLY 2
LEFT REAR SPEAKER ASSEMBLY 3
LT BLU WIRE
LT GRN WIRE
MODE
ON HOOK
ORG/ WIRE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
REAR SEAT ENTERTAINMENT CIRCUIT
RED WIRE
RIGHT FRONT SPEAKER ASSEMBLY 1
RIGHT REAR HEADER SPEAKER ASSEMBLY
RIGHT REAR SPEAKER ASSEMBLY 2
RIGHT REAR SPEAKER ASSEMBLY 3
RL RR
RLD
RRD
SEEK
SPD WUI MI+ SLDI MO+ TMUT
SPIRAL CABLE SUB-ASSEMBLY (IN STEERING COLUMN)
STEERING PAD SWITCH ASSEMBLY
STEERING PAD SWITCH ASSEMBLY W/ MODULATOR
STEREO COMPONENT AMPLIFIER ASSEMBLY (RIGHT REAR OF LUGGAGE COMPT)
TWL+ TWR+ WFL+
VIO WIRE
VOICE
VOLUME-
WFL-
WFR+ TWL- TWR-
WFR-
WHT WIRE
WHT/BLK WIRE
WUO MI- SLDO MO-
YEL WIRE
Go to component -> Navigation circuit (1 of 3) -> LEFT REAR RIGHT REAR SPEAKER SPEAKER ASSEMBLY ASSEMBLY
