Lexus LS IV (2006-2012) left rear headrest motor, position sensor Wiring diagram
This page shows the only wiring diagram for the component.left rear headrest motor, position sensor, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left rear headrest motor, position sensor (1 of 1)
5- SEATER
BLK WIRE
BLU WIRE
BRN WIRE
COOLING BOX ILLUMINATION LIGHT
COURTESY LIGHT SWITCH (ARMREST)
EXHAUST GAS SENSOR
FROM
FROM SEAT VIBRATOR SWITCH (DIAGRAM 5 OF 6)
FUEL FUEL INJECTOR 1 INJECTOR 4 SHIELD SHIELD
FUEL FUEL INJECTOR 8 INJECTOR 3 SHIELD SHIELD
FUEL INJECTOR 2 SHIELD
FUEL INJECTOR 5 SHIELD
FUEL INJECTOR 6 SHIELD
FUEL INJECTOR 7 SHIELD
FUEL SENDER GAUGE
HIGH MOUNTED STOP LIGHT
HOOD COURTESY SWITCH
LEFT FRONT DOOR CONTROL ECU
LEFT FRONT POWER SEAT CONTROL ECU, SWITCH
LEFT FRONT SEAT CLIMATE CONTROL ECU
LEFT FRONT SEAT INNER BELT SWITCH
LEFT HEADLIGHT
LEFT REAR DOOR CONTROL ECU
LEFT REAR HEADREST MOTOR, POSITION SENSOR
LEFT REAR LEFT REAR POWER SEAT SEAT CLIMATE CONTROL CONTROL ECU ECU
LEFT REAR SEAT
NCA WIRE
NOISE FILTER (REAR WINDOW DEFOGGER)
OCCUPANT DETECTION ECU
POWER TRUNK LID CONTROL ECU
REAR CONSOLE SWITCH
REAR SEAT ENTERTAINMENT TABLE SWITCH
RIGHT FRONT DOOR CONTROL ECU
RIGHT FRONT POWER SEAT CONTROL ECU, SWITCH
RIGHT FRONT SEAT CLIMATE CONTROL ECU
RIGHT FRONT SEAT INNER BELT SWITCH
RIGHT HEADLIGHT
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (6 of 6) -> LEFT REAR HEADREST MOTOR, POSITION SENSOR
