Lexus LS IV (2006-2012) left height adjustable anchor switch Wiring diagram
This page shows the only wiring diagram for the component.left height adjustable anchor switch, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left height adjustable anchor switch (1 of 1)
BCUT
BDR
BLK WIRE
BLU WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
CPUB
D DOOR 1 FUSE
D DOOR 2 FUSE
D MPX-B 1 FUSE
DOWN
DRIVER SIDE J/B (LEFT END OF DASH)
DSDN
DSE
DSUP
FUSE
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HOT IN ON OR START PASSENGER SIDE J/B (RIGHT END OF DASH) FUSE
J/B 4 (RIGHT SIDE OF DASH)
LEFT FRONT MULTIPLEX NETWORK DOOR ECU (DRIVER'S DOOR)
LEFT FRONT SEAT MEMORY SWITCH
LEFT HEIGHT ADJUSTABLE ANCHOR SWITCH
LT GRN WIRE
MSW
MSWE
ORG/ WIRE
P DOOR 1 FUSE
P DOOR 2 FUSE
P MPX B FUSE
P-D/C CUT FUSE
PNK MSW WIRE
PNK WIRE
PSDN
PSE
PSUP
RED WIRE
RIGHT FRONT MULTIPLEX NETWORK DOOR ECU (FRONT PASSENGER'S DOOR)
RIGHT HEIGHT ADJUSTABLE ANCHOR SWITCH
RIGHT POWER SEAT MEMORY SWITCH
SET-
SIG
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Memory power shoulder belt anchorage circuit (1 of 2) -> LEFT HEIGHT ADJUSTABLE ANCHOR SWITCH
