Lexus LS IV (2006-2012) hot at all times vvt fuse Wiring diagram
This page shows the only wiring diagram for the component.hot at all times vvt fuse, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram hot at all times vvt fuse (1 of 1)
A/F FUSE
A/F RELAY
ACCR
BLK WIRE
BLU WIRE
BRN WIRE
COMPUTER DATA LINES SYSTEM
DRIVER SIDE J/B (LEFT END OF DASH)
EFI FUSE
EFI-B FUSE
ELECTRIC POWER CONTROL ECU (RIGHT END OF DASH)
ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
HOT AT ALL TIMES VVT FUSE
HOT IN ON OR START E/G RM-
J/B 4 (RIGHT SIDE OF DASH)
MAIN BODY ECU (LEFT END OF DASH)
NCA WIRE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RED WIRE
SKSW
STARTING/ CHARGING SYSTEM
STOP LIGHT SWITCH (LEFT SIDE OF DASH)
STR+
STSW
TACH
VIO WIRE
VVT LH RELAY
VVT RH RELAY
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 4.6l (2 of 7) -> HOT AT ALL TIMES VVT FUSE
