Lexus LS IV (2006-2012) height control compressor motor Wiring diagrams
This page contains all the electrical diagrams for the component. height control compressor motor, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram height control compressor motor (1 of 2)
A/C COMPRESSOR
BLK WIRE
BLU WIRE
BRAKE ACCUMULATOR PUMP
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
EFI FRONT MAIN CONTROL RELAY
EFI MAIN 2 RELAY
ENGINE CONTROL MODULE
FAN
FRONT WIPER DEICER
HEADLIGHT CLEANER RELAY
HEIGHT CONTROL COMPRESSOR MOTOR
LEFT A/F H-LP LO RELAY RELAY
LEFT FOG LIGHT
LEFT FRONT SUSPENSION CONTROL ACTUATOR
LEFT VVT RELAY
NOISE FILTER (GHOST BUSTER)
POWER STEERING DC/DC CONVERTER
PTC HTR 2 RELAY
PTC PTC HTR 3 HTR 1 RELAY RELAY R/B 5 (RIGHT FRONT OF ENGINE COMPT)
RELAY
RELAY ENGINE ROOM R/B 1 (RIGHT REAR OF ENGINE COMPT)
RIGHT FOG LIGHT
SKID CONTROL ECU
SKID WIPER WASHER CONTROL MOTOR MOTOR ECU
TRANSMISSION CONTROL MODULE
WASHER FLUID LEVEL SENSOR
WHT WIRE
WHT/BLK WIRE
WIRELESS DOOR LOCK BUZZER
Go to component -> Ground distribution circuit (1 of 6) -> HEIGHT CONTROL COMPRESSOR MOTOR
Wiring diagram height control compressor motor (2 of 2)
A/F RELAY
ABS FR MTR FOG RELAY RELAY ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
BLK WIRE
BLU WIRE
BRAKE ACTUATOR ASSEMBLY SHIELD
BRN WIRE
EFI MAIN RELAY
FAN
FRONT HEIGHT CONTROL VALVE
HEATER WATER PUMP ASSEMBLY
HEIGHT CONTROL COMPRESSOR MOTOR
HEIGHT CONTROL EXHAUST VALVE
IGCT IGCT RELAY RELAY
INVERTER WATER PUMP MOTOR ASSEMBLY
JUNCTION CONNECTOR SHIELD
LEFT BRAKE FRONT ACTUATOR SPEED ASSEMBLY SENSOR SHIELD SHIELD
MULTIPLEX NETWORK FRONT LIGHT ECU
MULTIPLEX NETWORK FRONT LIGHT ECU SHIELD
OIL PUMP RELAY
PANEL)
POWER STEERING ECU ASSEMBLY SHIELD
POWER TRUNK LID CONTROL ECU SHIELD
REAR ACTIVE STABILIZER CONTROL ECU ASSEMBLY SHIELD
REAR CONSOLE SWITCH SHIELD
REAR JUNCTION JUNCTION BLOCK CONNECTOR ECU SHIELD SHIELD
RED WIRE
RELAY ENGINE ROOM R/B 5 (RIGHT FRONT OF ENGINE COMPT)
RELAY RELAY
RIGHT FRONT ABSORBER CONTROL ACTUATOR
RIGHT FRONT SPEED SENSOR SHIELD
RIGHT LEFT H-LP LO H-LP LO RELAY RELAY
RIGHT REAR SPEED SENSOR SHIELD
SEAT BELT JUNCTION CONTROL CONNECTOR ECU SHIELD SHIELD
STEERING CONTROL ECU SHIELD
VVT LH RELAY
W/ CONVERTER INVERTER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (2 of 7) -> HEIGHT CONTROL COMPRESSOR MOTOR
