Lexus LS IV (2006-2012) electronically controlled transmission pattern select switch Wiring diagram
This page shows the only wiring diagram for the component.electronically controlled transmission pattern select switch, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram electronically controlled transmission pattern select switch (1 of 1)
+B BATT
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BLU/RED WIRE
BRN WIRE
CAN (+)
COMPUTER DATA LINES SYSTEM
CONSOLE SWITCH
E/G
ECU-IG FUSE
EFI FUSE
EFI MAIN 2 RELAY
EFI MAIN FUSE
EFI MAIN RELAY
EFI- MAIN 2 FUSE
ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
ENGINE CONTROLS SYSTEM
ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT)
ETCS FUSE
FUSE
GRN WIRE
GRN/RED WIRE
GRN/YEL WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/B 4 (RIGHT SIDE OF DASH)
MPX
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RED WIRE
STARTING/ CHARGING SYSTEM
STP STA
TRANSMISSION CONTROL MODULE (LEFT SIDE OF ENGINE COMPT)
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Transmission circuit (1 of 4) -> ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH
