Lexus LS IV (2006-2012) cpub cann canp computer data lines system Wiring diagram
This page shows the only wiring diagram for the component.cpub cann canp computer data lines system, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram cpub cann canp computer data lines system (1 of 1)
1 2 5 8 18 6 3 11 10 9 GND PWE BDRJ
1 2 5 8 3 11 6 18 10 9 GND PWE BDRJ
AUTO
AUTO DOWN
AUTO UP
BDR SIG
BLK WIRE
BLU WIRE
BRN WIRE
CANN CANP
COMPUTER DATA LINES SYSTEM
CPUB CANN CANP COMPUTER DATA LINES SYSTEM
DOWN
FUSE
GND LED
GRY WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/C
LED
LEFT REAR DOOR CONTROL ECU (LEFT REAR DOOR)
LEFT REAR POWER WINDOW REGULATOR MOTOR (LEFT REAR DOOR)
LEFT REAR POWER WINDOW SWITCH
LIN
LUGGAGE ROOM J/B (LEFT SIDE OF LUGGAGE COMPT)
ORG/ WIRE
P RR DOOR FUSE
PASSENGER SIDE J/B (RIGHT END OF DASH)
RED WIRE
RIGHT REAR DOOR
RIGHT REAR DOOR CONTROL ECU (INSIDE RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW REGULATOR MOTOR
RIGHT REAR POWER WINDOW SWITCH
RR MPX-B 2 FUSE
SGND
SIG CPUB BDR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power windows circuit (3 of 3) -> CPUB CANN CANP COMPUTER DATA LINES SYSTEM
