Lexus LS IV (2006-2012) bbz cbz ee Wiring diagram
This page shows the only wiring diagram for the component.bbz cbz ee, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram bbz cbz ee (1 of 1)
2 1 TX+ TX-
BBZ CBZ EE
BLK WIRE
BLU WIRE
BUMPER FASCIA)
CENTER JUNCTION BLOCK J/B 4 (RIGHT SIDE OF DASH)
CENTER JUNCTION BLOCK J/B 5 (LEFT SIDE OF DASH)
CLEARANCE WARNING BUZZER 1 (UNDER CENTER OF DASH)
CLEARANCE WARNING BUZZER 2 (CENTER FRONT OF LUGGAGE COMPT)
COMPUTER DATA LINES SYSTEM
DISPLAY, NAVIGATION MODULE DISPLAY
EF CV+ CGND
FUSE
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR ACC
HOT IN ON OR START
LEFT FRONT SIDE ULTRASONIC SENSOR 1 (LEFT SIDE OF FRONT BUMPER FASCIA)
LT GRN WIRE
NCA WIRE
ORG/ WIRE
P MPX B FUSE
P-ACC FUSE
PARKING ASSIST ECU (RIGHT END END OF DASH)
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RADIO 1 FUSE
RED WIRE
RIGHT FRONT SIDE ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT
TX- TX+
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Parking assistant circuit (1 of 2) -> BBZ CBZ EE
