Lexus LS IV (2006-2012) air conditioning, headlights systems Wiring diagram
This page shows the only wiring diagram for the component.air conditioning, headlights systems, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram air conditioning, headlights systems (1 of 1)
A/C W/P
A/F RELAY
ABS
ABS FUSE FUSE
ABS MTR RELAY
AIR CONDITIONING, HEADLIGHTS SYSTEMS
AIR NAVIGATION, CONDITIONING, SUPPLEMENTAL COOLING RESTRAINTS FANS SYSTEM SYSTEM
ANTI-LOCK BRAKES, CRUISE CONTROL, SUPPLEMENTAL RESTRAINTS SYSTEMS
ANTI-LOCK BRAKES, CRUISE FROM ENGINE CONTROL ROOM R/B 2 SYSTEMS (DIAGRAM 2 OF 6)
BLK WIRE
BLU WIRE
CRUISE CONTROL, ANTI-LOCK BRAKES SYSTEMS
D MPX-B 1 FUSE
D MPX-B 2 FUSE
DC-
DEFOGGER SYSTEM
DEICER FUSE
DOME FUSE
E/G RM NV IR FUSE FUSE
E/G RM-
ECU-B FUSE
ELECTRONIC POWER STEERING SYSTEM
ENGINE CRUISE CONTROLS CONTROL, SYSTEM ENGINE CONTROLS SYSTEMS
EPS ECU FUSE
FR CTRL ALT FUSE
FR CTRL BAT FUSE
FR FOG RELAY
FROM FUSIBLE LINK BLOCK ASSEMBLY 1 (DIAGRAM 1 OF 6)
FROM PASSENGER SIDE J/B (DIAGRAM 4 OF 6)
FUSE
GRN WIRE
GRY WIRE
HEADLIGHTS SYSTEM
INSTRUMENT CLUSTER, INTERIOR LIGHTS SYSTEMS
INTERIOR LIGHTS, ANTI-THEFT SYSTEMS
LH H-LP LO RELAY
LT GRN WIRE
MEMORY GARAGE DOOR SYSTEMS OPENER, INTERIOR LIGHTS SYSTEMS
MEMORY, INSTRUMENT SEATS, CLUSTER, INTERIOR SOUND LIGHTS SYSTEMS SYSTEMS
PNK WIRE
RED WIRE
RELAY
RH H-LP LO RELAY
VVT FUSIBLE LINK ETCS FUSE
WHT WIRE
WHT/BLK WIRE
WIP FUSE
WIPER/ WASHER SYSTEM
YEL WIRE
Go to component -> Power distribution circuit (5 of 6) -> AIR CONDITIONING, HEADLIGHTS SYSTEMS
