Lexus LS IV (2006-2012) a/c infrared rays sensor Wiring diagrams
This page contains all the electrical diagrams for the component. a/c infrared rays sensor, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
a/c infrared rays sensor wiring diagram (1 of 2)
A/C AMPLIFIER
A/C INFRARED RAYS SENSOR
AIR SUSPENSION CONTROL ECU
BLK WIRE
CENTER AIR BAG ECU
CLOCK DRIVER MONITOR ECU
COMBINATION METER
D-ACC RELAY
DCM (TELEMATICS TRANSCEIVER)
DLC 3
FRONT CIGARETTE LIGHTER
GLOVE BOX ILLUMINATION LIGHT
ID CODE FLASHER BOX RELAY
J/B 3 (RIGHT SIDE OF DASH)
J/B 5 (LEFT SIDE OF DASH)
LEFT VISOR
LUGGAGE COMPT DOOR OPENER CANCEL SWITCH
MAIN BODY ECU
MULTIPLEX TILT, TELESCOPIC ECU
OUTER MIRROR SWITCH ASSEMBLY
OVERHEAD MODULE
POWER CONSOLE TILT BOX MOTOR ILLUMINATION LIGHT
POWER OUTLET
PRE- ELECTRIC COLLISION PARKING SYSTEM BRAKE CANCEL SWITCH SWITCH
REAR MAP LIGHT
RELAY
RIGHT LEFT FRONT FRONT SEAT SEAT CLIMATE CLIMATE CONTROL CONTROL SWITCH SWITCH
RIGHT VISOR
SHIFT LOCK CONTROL ECU
SHORT CONNECTOR
SHORT CONNECTOR (HEIGHT CONTROL)
SLIDING ROOF CONTROL ECU
SPIRAL CABLE
STEERING ANGLE SENSOR
STEERING LOCK ECU
WHT WIRE
WINDSHIELD WIPER SWITCH
Go to component -> Ground distribution circuit (3 of 6) -> A/C INFRARED RAYS SENSOR
a/c infrared rays sensor wiring diagram (2 of 2)
A/C AMPLIFIER
A/C AMPLIFIER SHIELD
A/C INFRARED RAYS SENSOR
AIR BAG ECU ASSEMBLY
AIRBAG ECU ASSEMBLY SHIELD
BLK WIRE
BRN WIRE
CENTER JUNCTION BLOCK J/B 3 (RIGHT SIDE OF DASH)
CENTER JUNCTION BLOCK J/B 5 (LEFT SIDE OF DASH)
CENTER JUNCTION BLOCK J/B 5 COMBINATION METER SHIELD
CLOCK ASSEMBLY
COMBINATION METER
CONSOLE POWER TILT BOX LIGHT MOTOR SUB- ASSEMBLY
D-ACC RELAY RELAY
DCM (TELEMATICS TRANSCEIVER)
DISPLAY, NAVIGATION MODULE DISPLAY SHIELD
DRIVER MONITOR ECU ASSEMBLY
ELECTRIC PARKING BRAKE SWITCH ASSEMBLY
FRONT CIGARETTE LIGHTER
GLOVE BOX ILLUMINATION LIGHT
HEADLIGHT DLC 3 SHIFT SWIVEL LOCK CONTROL MAIN ECU SWITCH
HEADLIGHT SWIVEL ECU ASSEMBLY SHIELD
ID CODE BOX
J/C
JUNCTION CONNECTOR SHIELD
LEFT FRONT SEAT CLIMATE CONTROL SWITCH
LUGGAGE COMPARTMENT DOOR OPENING CANCEL SWITCH ASSEMBLY
MAIN BODY ECU
MAIN BODY JUNCTION ECU CONNECTOR SHIELD SHIELD
MAIN CERTIFICATION BODY ECU ECU ASSEMBLY SHIELD SHIELD
MULTIPLEX OUTER TILT, MIRROR TELESCOPIC ECU SWITCH SHIELD ASSEMBLY SHIELD
MULTIPLEX TILT, TELESCOPIC ECU
OUTER MIRROR SWITCH ASSEMBLY
OVERHEAD MODULE
POWER OUTLET
PRE-COLLISION SYSTEM CANCEL SWITCH ASSEMBLY
ROOF CONTROL RIGHT FRONT BOX SEAT ASSEMBLY CLIMATE CONTROL SWITCH
SHIELD
SHORT CONNECTOR (CIGARETTE LIGHTER) (LEFT CENTER OF DASH)
SHORT CONNECTOR (HEIGHT CONTROL)
SLIDING ROOF CONTROL ECU
SPIRAL CABLE SUB-ASSEMBLY
STEERING LOCK ACTUATOR ASSEMBLY
STEERING SENSOR
STEERING SENSOR SHIELD
SUSPENSION CONTROL ECU
TURN SIGNAL FLASHER ASSEMBLY
WHT WIRE
WHT/BLK WIRE
WINDSHIELD WIPER SWITCH ASSEMBLY
YAW RATE JUNCTION COMBINATION SENSOR CONNECTOR METER SHIELD SHIELD SHIELD
Go to component -> Ground distribution circuit (4 of 7) -> A/C INFRARED RAYS SENSOR
