Lexus LS IV (2006-2012) 9 10 8 computer data lines system canp cann Wiring diagram

15 16 10 CANN CANP 9 10 8 COMPUTER DATA LINES SYSTEM CANP CANN BLK WIRE BLU WIRE BRN WIRE CANN CANP CENTER JUNCTION BLOCK J/B 3 (RIGHT SIDE OF DASH) CENTER JUNCTION BLOCK J/B 4 (RIGHT SIDE OF DASH) CERTIFICATION ECU ASSEMBLY (LEFT END OF DASH) CLS CLOSE COMBINATION METER COMPUTER DATA LINES SYSTEM D MPX-B 2 FUSE DCTY DOOR CONTROL RECEIVER (RIGHT REAR OF LUGGAGE COMPT) DOWN DOWN DRIVER SIDE J/B (LEFT END OF DASH) DRIVER'S DOOR ELECTRICAL KEY ANTENNA (RIGHT "C" PILLAR) ENGINE ROOM J/B 2 FUSE GND RSSI ASEL DATA +5 GRN WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START J/C KEY LOCK KUL LEFT FRONT MULTIPLEX NETWORK DOOR ECU LOCK ASSEMBLY LSWE MAIN BODY ECU (LEFT END OF DASH) MASTER IND MICRO COMPUTER MPX-B NCA WIRE OPN OPN DWN CLS UP P-J/B FUSE PASSENGER SIDE J/B (RIGHT END OF DASH) PNK KL WIRE PNK WIRE RDA ASEL RSSI CANP CANN RED WIRE S/ROOF FUSE SLIDING ROOF CONTROL SWITCH OVERHEAD MODULE (ROOF CONSOLE) SLIDING ROOF ECU (ROOF CONSOLE) SUPPLY POWER UL KEY UNLOCK UP UP WHT WIRE WHT/BLK WIRE YEL WIRE
