Lexus LS IV (2006-2012) 6 4 2 1 3 5 pnk eo so bo bi si ei Wiring diagrams
This page contains all the electrical diagrams for the component. 6 4 2 1 3 5 pnk eo so bo bi si ei, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
6 4 2 1 3 5 pnk eo so bo bi si ei wiring diagram (1 of 2)
1 16 +BS PNK WIRE
1 3 5 BI SI EI
1 5 3 2 4 6 BI EI SI BO SO EO
15 16 CANH CANL
34 27 18 NE- NE+ VC
5 3 1 2 4 6 EI SI BI BO SO EO
6 4 2 1 3 5 EO SO BO BI SI EI
6 4 2 1 3 5 PNK EO SO BO BI SI EI WIRE
BLK WIRE
BLU WIRE
BRN WIRE
CB+
CB+ CV+
CGND
COMBINATION METER
COMPUTER DATA LINES SYSTEM
CV+
D MPX-B 2 FUSE
DRIVER SIDE J/B (LEFT END OF DASH)
ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM J/B 2
GRN WIRE
HOT AT ALL TIMES
HOT IN ON OR START
HYBRID VEHICLE CONTROL ECU (LEFT FRONT OF ENGINE COMPT)
LEFT FRONT CENTER ULTRASONIC SENSOR 1 (LEFT SIDE OF FRONT BUMPER FASCIA)
LEFT FRONT ULTRASONIC SENSOR 1 (LEFT SIDE OF FRONT BUMPER FASCIA)
LEFT REAR CENTER ULTRASONIC SENSOR 1 (LEFT SIDE OF REAR BUMPER FASCIA)
LEFT REAR ULTRASONIC SENSOR 1 (LEFT SIDE OF REAR BUMPER FASCIA)
MASTER
MICRO COMPUTER
MPX+B IND
NCA WIRE
NE- NE VC
ORG/ WIRE
P J/B (RIGHT SIDE OF FUSE ENGINE COMPT)
PARK/NEUTRAL RB POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
PARKING ASSIST ECU (RIGHT END OF DASH)
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
RED WIRE
RIGHT FRONT CENTER ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT BUMPER FASCIA)
RIGHT FRONT ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT BUMPER FASCIA)
RIGHT REAR CENTER ULTRASONIC SENSOR 1
RIGHT REAR ULTRASONIC SENSOR 1 (RIGHT SIDE OF REAR BUMPER FASCIA)
SUPPLY POWER
TELEVISION CAMERA ASSEMBLY (CENTER REAR OF LUGGAGE COMPT LID)
WHT WIRE
YEL WIRE
Go to component -> Parking assistant circuit (2 of 2) -> 6 4 2 1 3 5 PNK EO SO BO BI SI EI WIRE
6 4 2 1 3 5 pnk eo so bo bi si ei wiring diagram (2 of 2)
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 CBZ EE
1 3 5 BI SI EI
11 1 12 2 3 IG CLEARANCE SONAR SWITCH CANP CANN
14 13 CANH CANL
18 14 ES
3 5 1 2 4 6 SI EI BI BO SO EO
5 3 1 2 4 6 EI SI BI BO SO EO
6 4 2 1 3 5 EO SO BO BI SI EI
6 4 2 1 3 5 PNK EO SO BO BI SI EI WIRE
BLK WIRE
BLU WIRE
BOF
BOR
BRN WIRE
BUZZER
CAN CONTROLLER
CAN I/F
CANN CANP CANL CANH
CLEARANCE SONAR ECU (RIGHT END OF DASH)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DRIVER SIDE J/B (LEFT END OF DASH)
E/G
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
FRONT CLEARANCE WARNING BUZZER (CENTER OF DASH)
FUSE
GRN WIRE
GRN/RED WIRE
HOT AT ALL TIMES
HOT IN ON OR START
J/B 4 (RIGHT SIDE OF DASH)
J/B 5 (LEFT SIDE OF DASH)
LED DRIVER
LEFT FRONT CENTER ULTRASONIC SENSOR 1 (LEFT SIDE OF FRONT BUMPER FASCIA)
LEFT FRONT SIDE ULTRASONIC SENSOR 1 (LEFT SIDE OF FRONT BUMPER FASCIA)
LEFT FRONT ULTRASONIC SENSOR 1 (LEFT SIDE OF FRONT BUMPER FASCIA)
LEFT REAR CENTER ULTRASONIC SENSOR 1 (LEFT SIDE OF REAR BUMPER FASCIA)
LEFT REAR ULTRASONIC SENSOR 1 (LEFT SIDE OF REAR BUMPER FASCIA)
MASTER IND
MPX-B 1 FUSE
ORG/ WIRE
OUTER MIRROR SWITCH ASSEMBLY
P-J/B FUSE
PARK/ RB NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSM- ISSION)
PASSENGER SIDE J/B (RIGHT END OF DASH)
PNK WIRE
REAR CLEARANCE WARNING BUZZER (UNDER REAR PARCEL SHELF)
RED WIRE
RIGHT FRONT CENTER ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT BUMPER FASCIA)
RIGHT FRONT SIDE ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT BUMPER FASCIA)
RIGHT FRONT ULTRASONIC SENSOR 1 (RIGHT SIDE OF FRONT BUMPER FASCIA)
RIGHT REAR CENTER ULTRASONIC SENSOR 1 (RIGHT SIDE OF REAR BUMPER FASCIA)
RIGHT REAR ULTRASONIC SENSOR 1 (RIGHT SIDE OF REAR BUMPER FASCIA)
SOF BBZ EF
SOR
VIO WIRE
WHT WIRE
WHT/BLK WIRE
Go to component -> Rear sonar circuit -> 6 4 2 1 3 5 PNK EO SO BO BI SI EI WIRE
