Lexus LS IV (2006-2012) 31 32 tx+ tx- Wiring diagrams
This page contains all the electrical diagrams for the component. 31 32 tx+ tx-, in which he is found in the car Lexus LS IV (2006-2012). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
Wiring diagram 31 32 tx+ tx- (1 of 5)
10 9 CANN CANP
12 6 CANN CANP
13 22 CANH CANL
22 21 CANL CABH
3 4 CANH CANL
31 32 TX+ TX-
7 8 CANH CANL
A/C AMPLIFIER (CENTER OF DASH)
AIR SUSPENSION CONTROL ECU (RIGHT END OF DASH)
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
CENTER AIR BAG ECU (UNDER CENTER FLOOR CONSOLE)
CLEARANCE SONAR ECU (RIGHT END OF DASH)
CLOCK
DISPLAY, NAVIGATION MODULE DISPLAY (W/ MULTI DISPLAY)
GRN WIRE
LT GRN WIRE
OF DASH)
PARKING ASSIST ECU (RIGHT END OF DASH)
PNK WIRE
RED WIRE
RIGHT FRONT DOOR CONTROL ECU (FRONT PASSENGER'S DOOR)
RIGHT REAR DOOR CONTROL ECU (INSIDE RIGHT REAR DOOR)
STEERING CONTROL ECU (RIGHT SIDE OF DASH)
TIRE PRESSURE WARNING ECU (RIGHT END
TX+1
TX-1
VIO WIRE
W/ ADVANCED PARKING GUIDANCE
W/ MULTI DISPLAY
W/O ADVANCED PARKING GUIDANCE
W/O MULTI DISPLAY
WHT WIRE
YEL WIRE
Go to component -> High/low bus circuit (2 of 3) -> 31 32 TX+ TX-
