Lexus LS IV (2006-2012) 3 20 21 10 11 12 24 vb+ vsw msw vgnd vib- vib+ sg Wiring diagram
This page shows the only wiring diagram for the component.3 20 21 10 11 12 24 vb+ vsw msw vgnd vib- vib+ sg, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 3 20 21 10 11 12 24 vb+ vsw msw vgnd vib- vib+ sg (1 of 1)
1 2 3 4 5 6 7 8 IG
21 20 3 10 11 12 24 MSW VSW VB+ VGND VIB- VIB+ SG
3 20 21 10 11 12 24 VB+ VSW MSW VGND VIB- VIB+ SG
BLK WIRE
BLU WIRE
BRN WIRE
DRIVER SIDE J/B (LEFT END OF DASH)
GRY WIRE
HOT AT ALL TIMES D RR SEAT FUSE
HOT AT ALL TIMES PASSENGER P RR SIDE J/B SEAT (RIGHT END FUSE OF DASH)
LEFT REAR POWER SEAT CONTROL ECU (LEFT REAR SEAT BACK)
LEFT SEAT VIBRATOR (IN LEFT REAR SEAT BACK)
LIN
LT BLU WIRE
LUGGAGE ROOM J/B
NCA WIRE
PNK WIRE
RELAY ENERGIZED
RIGHT REAR POWER SEAT CONTROL ECU (RIGHT REAR SEAT BACK)
RIGHT SEAT VIBRATOR (IN RIGHT REAR SEAT BACK) (RIGHT SIDE OF LUGGAGE COMPT)
RR- RR- (LEFT SIDE OF LUGGAGE FUSE FUSE COMPT)
SEAT VIBRATION ECU
SEAT VIBRATOR SWITCH
VIO WIRE
VSWR MSWR VSWL MSWL PNK WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Vibrating seats circuit -> 3 20 21 10 11 12 24 VB+ VSW MSW VGND VIB- VIB+ SG
