Lexus LS IV (2006-2012) 27 2 stsw star Wiring diagram
This page shows the only wiring diagram for the component.27 2 stsw star, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 27 2 stsw star (1 of 1)
15 22 6 IG
27 2 STSW STAR
BATTERY
BLK WIRE
BLU WIRE
BRN WIRE
CHARGING CIRCUIT
D-ACC FUSE
DRIVER SIDE J/B (LEFT END OF DASH)
ECU-IG FUSE
ELECTRIC POWER CONTROL ECU (RIGHT END OF DASH)
ENGINE CONTROL MODULE (LEFT FRONT OF ENGINE COMPT)
ENGINE ROOM J/B 2 (RIGHT SIDE OF ENGINE COMPT)
ENGINE ROOM R/B 2 (RIGHT SIDE OF ENGINE COMPT)
FUSE
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT W/ D-ACC RELAY ENERGIZED
JUNCTION CONNECTOR
MAIN BODY ECU (LEFT END OF DASH)
PARK/NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION)
PASSENGER SIDE J/B (RIGHT END OF DASH)
RED WIRE
RELAY ENERGIZED
ST CUT RELAY
ST FUSE
ST RELAY
STARTER
STR+
STSW
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Starting circuit -> 27 2 STSW STAR
