Lexus LS IV (2006-2012) 11 12 13 14 fsr+ fsr- bsw bgnd Wiring diagram
This page shows the only wiring diagram for the component.11 12 13 14 fsr+ fsr- bsw bgnd, which is found in the car Lexus LS IV (2006-2012). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram 11 12 13 14 fsr+ fsr- bsw bgnd (1 of 1)
11 12 13 14 FSR+ FSR- BSW BGND
13 22 CANH CANL
22 16 FSR- FSR+
AIR BAG ECU ASSEMBLY (UNDER CENTER FLOOR CONSOLE)
BLK WIRE
BLU WIRE
BRN WIRE
BUCKLE SWITCH
CAN I/F
CENTER JUNCTION BLOCK J/B 5 (LEFT SIDE OF DASH)
COMBINATION METER
COMPUTER DATA LINES SYSTEM
DISPLAY, NAVIGATION MODULE DISPLAY
DRIVER'S SEAT BELT IND
FRONT PASSENGER'S SEAT BELT WARNING LIGHT
FUSE
GRN WIRE
HOT AT ALL TIMES DRIVER SIDE J/B (LEFT END OF DASH) D MPX-B 1 FUSE
HOT IN ON OR START
LEFT FRONT SEAT INNER BELT SWITCH (UNDER DRIVER'S SEAT)
LT BLU WIRE
MICRO COMPUTER
OCCUPANT DETECTION ECU (UNDER FRONT PASSENGER'S SEAT)
P-J/B FUSE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PBEW
PNK WIRE
POWER SUPPLY
RED WIRE
RIGHT FRONT SEAT INNER BELT ASSEMBLY
SKID CONTROL ECU ASSEMBLY (LEFT REAR OF ENGINE COMPT)
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Seat belt warning circuit -> 11 12 13 14 FSR+ FSR- BSW BGND
