Wiring diagram 1 2 5 8 3 11 6 18 10 9 gnd pwe bdrj (1 of 2)
1 2 5 8 18 6 3 11 10 9 GND PWE BDRJ
1 2 5 8 3 11 6 18 10 9 GND PWE BDRJ
5 4 10 7 9 2 1 LED AUTO
AUTO
AUTO DOWN
AUTO LED LIN
AUTO UP
BDR SIG
BLK WIRE
BLU WIRE
BRN WIRE
CANL CANH RSSI ASEL RDA
CANN
CANN CANP
CANP
CENTER JUNCTION BLOCK J/B 3 (RIGHT SIDE OF DASH)
CENTER JUNCTION BLOCK J/B 4 (RIGHT SIDE OF DASH)
CERTIFICATION ECU ASSEMBLY (LEFT END OF DASH)
COMPUTER DATA LINES SYSTEM
CPUB CANN CANP
D RR DOOR FUSE
DCTY
DOOR CONTROL RECEIVER (RIGHT REAR OF LUGGAGE COMPT)
DOWN
DOWN UP
DRIVER SIDE J/B (LEFT END OF DASH)
FUSE
GND LED
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
HOT AT ALL TIMES P MPX-B FUSE
HOT IN ON OR START
LED
LEFT REAR MULTIPLEX NETWORK DOOR ECU (LEFT REAR DOOR)
LEFT REAR POWER REGULATOR WINDOW MOTOR ASSEMBLY (LEFT REAR DOOR)
LEFT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
LIN
LUGGAGE ROOM J/B (LEFT SIDE OF LUGGAGE COMPT)
MAIN BODY ECU
NCA WIRE
ORG/ WIRE
P RR DOOR FUSE
PASSENGER SIDE J/B (RIGHT END OF DASH)
PASSENGER SIDE J/B (RIGHT SIDE OF DASH)
RED WIRE
RIGHT REAR MULTIPLEX NETWORK DOOR ECU (RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW REGULATOR MOTOR ASSEMBLY (RIGHT REAR DOOR)
RIGHT REAR POWER WINDOW REGULATOR SWITCH ASSEMBLY
RR MPX-B 2 FUSE
RSSI ASEL DATA +5 GND
SGND
SIG CPUB BDR
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Power windows circuit (2 of 2) -> 1 2 5 8 3 11 6 18 10 9 GND PWE BDRJ
Wiring diagram 1 2 5 8 3 11 6 18 10 9 gnd pwe bdrj (2 of 2)
