Lexus LS IV (2006-2012) 1 10 rmvr rm+r Wiring diagram

1 10 RMVR RM+R 6 11 3 16 9 10 1 BDR CPUB SIG 6 5 13 14 VSSR RVC HSSR AUTO RETRACTOR SWITCH OUTER MIRROR SWITCH BDR CPUB SIG BCUT CANP CANN GND BLK WIRE BLU WIRE BRN WIRE CANN CANP CANP CANN GND CENTER JUNCTION BLOCK J/B 4 (RIGHT SIDE OF DASH) CENTER JUNCTION BLOCK J/B 5 (LEFT SIDE OF DASH) COMPUTER DATA LINES SYSTEM DOOR 1 FUSE DOOR 2 FUSE DRIVER SIDE J/B (LEFT END OF DASH) FUSE GRN WIRE GRY WIRE HOT AT ALL TIMES HOT AT ALL TIMES PASSENGER SIDE J/B (RIGHT END OF DASH) HYBRID VEHICLE CONTROL ECU (LEFT FRONT OF ENGINE COMPT) LEFT FRONT MULTIPLEX NETWORK DOOR ECU (DRIVER'S DOOR) LEFT FRONT POWER SEAT CONTROL ECU, SWITCH (UNDER DRIVER'S SEAT) LEFT FRONT SEAT MEMORY SWITCH LEFT OUTER REAR VIEW MIRROR (AT MIRROR) LEFT/RIGHT LT GRN WIRE MAIN BODY ECU ALTB MIRROR POSITION SENSOR MPX-B FUSE MSW MSWE ORG/ WIRE OUTER MIRROR SWITCH ASSEMBLY P-D/C CUT FUSE PARK/ NEUTRAL POSITION SWITCH (RIGHT SIDE OF TRANSMISSION) PNK ILL+ WIRE PNK WIRE RED WIRE RED/WHT WIRE RELAY RELAY MPX B 1 FUSE RETRACTABLE MIRROR MOTOR RIGHT FRONT MULTIPLEX NETWORK DOOR ECU (FRONT PASSENGER'S DOOR) RIGHT OUTER REAR VIEW MIRROR (AT MIRROR) RMHR SET- SKID CONTROL ECU ASSEMBLY (LEFT REAR OF ENGINE COMPT) UP/DOWN VIO WIRE WHT WIRE WHT/BLK WIRE YEL WIRE YEL/BLK WIRE
