Lexus LS III facelift (2003-2006) Fuel door release circuit

2 10 MPX+ BUBS BM (AT LEFT REAR QUARTERPANEL) COMBINATION SWITCH DRIVER SIDE J/B (AT LEFT KICK PANEL) DRIVER SIDE J/B ECU FUEL FUEL LID OPENER SWITCH FUEL OPN FUSE FUEL OPN(O) FUEL OPN(P) FUSE GRN/WHT WIRE HOT AT ALL TIMES IG (AT LEFT SIDE OF DASH) J/C 23 (REARWARD OF LEFT REAR FENDERWELL) LUGGAGE ROOM J/B (ON LEFT SIDE OF LUGGAGE COMPARTMENT) LUGGAGE ROOM J/B ECU MPX-B P-GND PASSENGER SIDE J/B (AT RIGHT KICK PANEL) POWER TILT, POWER TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH) RED WIRE RED/BLK WIRE VIO WIRE VIO/GRN WIRE WHT WIRE WHT/BLK WIRE
