Lexus LS III (2000-2003) Charging circuit

ALT FUSIBLE LINK ALT-S FUSIBLE LINK BATTERY BATTERY GROUND BLK WIRE BLU WIRE CHG COMBINATION METER COMPUTER DATA LINES SYSTEM ENGINE CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPARTMENT, IN PROTECTIVE CASE) ENGINE ROOM R/B 1 (LEFT FRONT OF ENGINE COMPT, BEHIND HEADLIGHT) FR IG FUSE FUSIBLE LINK BLOCK (ON RIGHT REAR OF ENGINE COMPARTMENT) GENERATOR GRY/BLK WIRE HOT IN ON OR START HOT IN ON OR START DRIVER SIDE J/B (LEFT KICK PANEL) GAUGE FUSE J/C 1, 2 (NEAR ENGINE CONTROL MODULE, IN PROTECTIVE CASE) J/C 16, 17 (BEHIND UPPER CENTER OF DASH) NCA WIRE PNK WIRE PNK/BLU WIRE RED WIRE RED/BLK WIRE WHT/BLK WIRE YEL WIRE
