Lexus LS III (2000-2003) rco rda rssi wiring diagram
This page shows the only wiring diagram for the component.rco rda rssi, which is found in the car Lexus LS III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
rco rda rssi wiring diagram (1 of 1)
10 13 2 BUBS MPX- MPX+
2 13 14 CLTB CLTS CLTE
5 7 8 MPX-B
7 15 HRLY
AUTOMATIC LIGHT CONTROL SENSOR (BEHIND UPPER CENTER OF DASH)
BLK WIRE
BLK/WHT WIRE
BLU WIRE
BRAKE FLUID LEVEL WARNING SWITCH (ON BRAKE MASTER CYLINDER RESERVOIR)
BRN WIRE
COMBINATION SWITCH
COMPUTER DATA LINES SYSTEM
DATA RSSI
DRIVER DOOR ECU (INSIDE FRONT OF LEFT FRONT DOOR) CTY
DRIVER SIDE J/B (AT LEFT KICK PANEL)
DRIVER SIDE J/B ECU
FUSE
GRN WIRE
GRY/BLK WIRE
HEAD
HOT AT ALL TIMES PASSENGER SIDE J/B (AT RIGHT KICK PANEL)
HOT IN RUN OR START
J/C 13 (BEHIND UPPER CENTER OF DASH)
J/C 14, 15 (BEHIND UPPER CENTER OF DASH)
J/C 7 (BELOW ENGINE ROOM 1 J/B)
LEFT FRONT DOOR COURTESY SWITCH
LUGGAGE ROOM J/B ECU (ON LEFT SIDE OF LUGGAGE COMPARTMENT)
MPX-IG
MPX-IG FUSE
ORG/ WIRE
PARKING BRAKE SWITCH (BEHIND LEFT SIDE OF DASH)
PNK WIRE
PNK/BLU WIRE
POWER TILT AND POWER TELESCOPIC ECU (BEHIND LEFT SIDE OF DASH)
RCO RDA RSSI
RED WIRE
RED/BLK WIRE
RED/BLU WIRE
RED/WHT WIRE
RED/YEL WIRE
SKID CONTROL ECU (BEHIND LEFT SIDE OF DASH)
THEFT DETERRENT ECU (BEHIND UPPER RIGHT CENTER OF DASH)
TRANSPONDER KEY COMPUTER (BEHIND UPPER CENTER OF DASH)
VIO/GRN WIRE
VIO/WHT WIRE
WHT WIRE
WHT/BLK WIRE
YEL/BLK WIRE
Go to component -> Headlamps circuit (1 of 2) -> RCO RDA RSSI
