Lexus LS III (2000-2003) (near engine control module, in protective case) wiring diagram
This page shows the only wiring diagram for the component.(near engine control module, in protective case), which is found in the car Lexus LS III (2000-2003). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
(near engine control module, in protective case) wiring diagram (1 of 1)
3 22 TC WFSE
AIR SUSPENSION ECU (BEHIND RIGHT SIDE OF DASH)
BLK WIRE
BLK/YEL WIRE
BRN WIRE
CG SG
COMBINATION METER
DATA LINK CONNECTOR 3 (BELOW LEFT SIDE OF DASH)
DRIVER SIDE J/B (AT LEFT KICK PANEL)
ENGINE CONTROL MODULE (ON LEFT FRONT OF ENGINE COMPT, IN PROTECTIVE CASE)
GRN WIRE
GRY WIRE
HOT AT ALL TIMES
J/C 13 (BEHIND UPPER CENTER OF DASH)
LT GRN/BLK WIRE
OBD FUSE
OPB TC TS WFSE BAT
PNK/BLK WIRE
SIL
SKID CONTROL ECU (BEHIND LEFT SIDE OF DASH)
TAC
TACH
WHT WIRE
WHT/BLK WIRE
WHT/GRN WIRE
Go to component -> Data link connector circuit -> (NEAR ENGINE CONTROL MODULE, IN PROTECTIVE CASE)
