Lexus LS III (2000-2003) front height control valve Wiring diagrams
This page contains all the electrical diagrams for the component. front height control valve, in which he is found in the car Lexus LS III (2000-2003). You can view various wiring diagrams where this component is used, as well as go to more detailed diagrams to see the complete connection and interaction in the system. All diagrams have links to quickly jump to the corresponding section with the component for easy viewing..
front height control valve wiring diagram (1 of 2)
ABSORBER CONTROL SWITCH
AIR SUS FUSIBLE LINK
AIR SUS RELAY
BLK WIRE
BLK/BLU WIRE
BLK/RED WIRE
BLU WIRE
BRN/BLK WIRE
BRN/WHT WIRE
BRN/YEL WIRE
CHS+
COMPUTER DATA LINES
DATA LINK CONNECTOR 3
FRO
FRONT HEIGHT CONTROL VALVE
FUSIBLE LINK BLOCK (RIGHT REAR OF ENGINE COMPARTMENT)
GRN/BLK WIRE
GRN/YEL WIRE
GRY WIRE
HEADLIGHT BEAM LEVEL CONTROL ECU
HEIGHT CONTROL COMPRESSOR
HEIGHT CONTROL EXHAUST VALVE
HEIGHT CONTROL SWITCH
HOT AT ALL TIMES
INSTRUMENT CLUSTER
J/C 12/13 (UPPER CENTER OF DASH)
JC-23
LEFT QUARTER PANEL)
LH -
LT GRN WIRE
LT GRN/BLK WIRE
LUGGAGE ROOM J/B
ORG/ WIRE
PASSENGER SIDE J/B (AT RIGHT KICK PANEL)
PNK WIRE
PNK/BLU WIRE
REAR HEIGHT CONTROL VALVE
RED/BLK WIRE
RED/WHT WIRE
RH-
RM+
SBF
SGF
SHFL
SHRL
SKID CONTROL ECU
TEMS SPORT IND LIGHT
VIO WIRE
VIO/GRN WIRE
VIO/YEL WIRE
WHT/BLK WIRE
WHT/BLU WIRE
WHT/GRN WIRE
WHT/RED WIRE
Go to component -> Electronic suspension circuit (2 of 2) -> FRONT HEIGHT CONTROL VALVE
front height control valve wiring diagram (2 of 2)
ABS MOTOR RELAY
ABS, TRAC, VSC ACTUATOR
BLK WIRE
BLOWER MOTOR
BRAKE FLUID LEVEL WARNING SWITCH
BRN WIRE
COOLING FAN ECU
EFI MAIN RELAY
ENGINE CONTROL MODULE
ENGINE HOOD COURTESY SWITCH
EXHAUST GAS SENSOR
FAN RELAY
FRONT HEIGHT CONTROL VALVE
FRONT WIPER MOTOR
HEADLIGHT CLEANER CONTROL RELAY
HEADLIGHT CLEANER MOTOR
HEIGHT CONTROL COMPRESSOR
HEIGHT CONTROL EXHAUST VALVE
J/C 3 (NEAR ENGINE CONTROL MODULE, IN PROTECTIVE CASE)
J/C 7 (BELOW ENGINE ROOM 1 J/B, ENGINE ROOM 1 R/B)
LEFT FRONT FOG LIGHT
LEFT FRONT PARKING LIGHT
LEFT FRONT SIDE MARKER LIGHT
LEFT FRONT SUSPENSION CONTROL ACTUATOR
LEFT FRONT TURN SIGNAL LIGHT
LEFT HEADLIGHT CONTROL ECU
RELAY RELAY
RIGHT FRONT FOG LIGHT
RIGHT FRONT PARKING LIGHT
RIGHT FRONT SIDE MARKER LIGHT
RIGHT FRONT SUSPENSION CONTROL ACTUATOR
RIGHT FRONT TURN SIGNAL LIGHT
RIGHT HEADLIGHT (HIGH BEAM)
RIGHT HEADLIGHT CONTROL ECU
SKID CONTROL ECU
WASHER LEVEL SENSOR
WASHER MOTOR LEFT HEADLIGHT (HIGH BEAM)
WHT WIRE
WHT/BLK WIRE
Go to component -> Ground distribution circuit (1 of 5) -> FRONT HEIGHT CONTROL VALVE
