Lexus LS III (2000-2003) ec (radiator left side support) wiring diagram

+B IGSW STA BATT +BM SIL 13 12 STPI STPO 2 13 5 6 17 12 4 7 26 EC MREL 2002-03 ACCELERATOR POSITION SENSOR (BEHIND LEFT CENTER OF DASH) BLK/ORG WIRE BLK/RED WIRE BLK/WHT WIRE BLK/YEL WIRE BLU/ORG WIRE BLU/RED WIRE BLU/WHT WIRE BRN/WHT WIRE BRN/YEL WIRE COMBINATION METER COMPUTER DATA LINES SYSTEM DATA LINK CONNECTOR 3 (BELOW LEFT SIDE OF DASH) DRIVER SIDE J/B (BEHIND LEFT KICK PANEL) DRIVER SIDE J/B ECU (LEFT KICK PANEL) EC (RADIATOR LEFT SIDE SUPPORT) ECT PWR. ECT SNOW EFI 1 FUSE EFI MAIN RELAY ELECTRONICALLY CONTROLLED TRANSMISSION PATTERN SELECT SWITCH ENGINE CONTROL MODULE (ECM) (LEFT FRONT OF ENGINE COMPT, IN PROTECTIVE CASE) ENGINE ROOM R/B 1 (LEFT FRONT OF ENGINE COMPT, BEHIND HEADLIGHT) EPTK VPTK ETCS FUSE FR IG FUSE GAUGE FUSE GRN/ORG WIRE GRY/BLK WIRE GRY/BLU WIRE HOT AT ALL TIMES HOT IN HOT IN ON OR START IGN FUSE II (RIGHT SIDE OF SHIFT LEVER) IK (RIGHT DASH SIDE PANEL) J/C 1, J/C 2 (NEAR ECM) J/C 13 (UPPER CENTER OF DASH) J/C 16, J/C 17 (UPPER CENTER OF DASH) J/C 3 (NEAR ECM) LT GRN/BLK WIRE MPX ORG/ WIRE PASSENGER SIDE J/B (BEHIND RIGHT KICK PANEL) PASSENGER SIDE J/B ECU (BEHIND RIGHT KICK PANEL) PNK/BLK WIRE PNK/NLK WIRE PWR PWR SNOW RED WIRE RED/BLK WIRE RED/YEL WIRE SHORT CONNECTOR SIL SNOW SPEEDO STA FUSE STOP FUSE STOPLIGHT SWITCH (ABOVE BRAKE PEDAL, ON BRACKET) TAC TACH TACH TC WFSE VPA EPA VCPA WHT/BLK WIRE WHT/GRN WIRE WSFE YEL WIRE YEL/BLK WIRE YEL/RED WIRE
