Lexus LS III (2000-2003) door lock control receiver (inner mirror) data rssi +5 wiring diagram

BLK WIRE BLU WIRE BRN WIRE CLS COMBINATION METER CTY CTY CTY DOME FUSE FUSE DOOR LOCK CONTROL RECEIVER (INNER MIRROR) DATA RSSI +5 DOWN UP OPN DRIVER DOOR ECU (INSIDE FRONT OF LEFT FRONT DOOR) DRIVER SIDE J/B (AT LEFT KICK PANEL) DWN UP GATEWAY-ECU (BEHIND LEFT SIDE OF DASH) GRN WIRE GRN/BLK WIRE GRN/YEL WIRE GRY WIRE HOT AT ALL TIMES HOT IN ON OR START HOT IN RUN DRIVER SIDE J/B (AT LEFT KICK PANEL) GAUGE FUSE IG OPN CLS J/C 10, J/C 12 (BEHIND UPPER CENTER OF DASH) J/C 14 (BEHIND UPPER CENTER OF DASH) J/C 16, J/C 17 (BEHIND UPPER CENTER OF DASH) LEFT FRONT DOOR COURTESY SWITCH LEFT REAR DOOR COURTESY SWITCH LEFT REAR DOOR ECU (INSIDE FRONT OF LEFT REAR DOOR) LT GRN WIRE LT GRN/RED WIRE MOON ROOF CONTROL ECU (AT FRONT OF ROOF OPENING) MPX OVERHEAD J/B (AT FRONT OF ROOF OPENING) IG P-IG FUSE PASSENGER SIDE J/B (AT RIGHT KICK PANEL) PNK PNK WIRE PNK WIRE PNK/BLU WIRE RDA RSSI RED WIRE RED/BLK WIRE RED/YEL WIRE RIGHT REAR DOOR COURTESY SWITCH RIGHT FRONT DOOR COURTESY SWITCH S/ROOF FUSE THEFT DETERRENT ECU (BEHIND RIGHT UPPER CENTER OF DASH) TRANSPONDER KEY COMPUTER (BEHIND UPPER CENTER OF DASH) WHT WIRE WHT/BLK WIRE YEL WIRE
