Lexus LC I (2016-2024) oil pump relay Wiring diagram
This page shows the only wiring diagram for the component.oil pump relay, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram oil pump relay (1 of 1)
AMD
BLK WIRE
BLK/BLU WIRE
BLU WIRE
BRN WIRE
DC/DC FUSE
ENGINE ROOM J/B 2
ENGINE ROOM R/B 1
FUSIBLE LINK BLOCK ASSEMBLY 1
GCS
GCSG
GMT
GMTG
GRF
GRFG
GRN WIRE
GRY WIRE
GSN
GSNG
HOT AT ALL TIMES
HYBRID VEHICLE GENERATOR
HYBRID VEHICLE MOTOR
HYBRID VEHICLE TRANSMISSION ASSEMBLY (REAR OF ENGINE COMPT)
INV W/ PMP FUSE
INV W/ PMP RELAY
INVERTER BUS-BAR PLATE SUB- ASSEMBLY
INVERTER W/ CONVERTER ASSEMBLY (RIGHT REAR OF ENGINE COMPT)
LT BLU WIRE
LT GRN WIRE
MCS
MCSG
MMT
MMTG
MRF
MRFG
MSN
MSNG
OIL PMP FUSE
OIL PUMP RELAY
ORG/ WIRE
PNK WIRE
PPL/BLK WIRE
PPL/RED WIRE
RED WIRE
SHIELD
VIO WIRE
WHT WIRE
WHT/BLK WIRE
YEL WIRE
Go to component -> Wiring diagram engine performance 3.5l hybrid, hybrid system circuit (2 of 11) -> OIL PUMP RELAY
