Lexus LC I (2016-2024) left lumbar support adjuster assembly Wiring diagram
This page shows the only wiring diagram for the component.left lumbar support adjuster assembly, which is found in the car Lexus LC I (2016-2024). This component is only found in one wiring diagram on your vehicle, and you can see its details here. If necessary, you can also go to other diagrams for this system for more information..
Wiring diagram left lumbar support adjuster assembly (1 of 1)
BLK WIRE
BLU WIRE
BRN WIRE
CANN
CANP
COMPUTER DATA LINES SYSTEM
GRN WIRE
GRY WIRE
LEFT FRONT MULTIPLEX NETWORK DOOR ECU
LEFT FRONT SEAT HEADREST ASSEMBLY
LEFT LIMIT SWITCH ASSEMBLY (INNER)
LEFT LIMIT SWITCH ASSEMBLY (OUTER)
LEFT LUMBAR SUPPORT ADJUSTER ASSEMBLY
LEFT POWER SEAT LIFT MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LEFT POWER SEAT RECLINING MOTOR (LEFT FRONT SEAT BACK FRAME SUB-ASSEMBLY)
LEFT POWER SEAT SLIDE MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LEFT POWER SEAT TILT MOTOR (LEFT FRONT SEAT ADJUSTER ASSEMBLY)
LT GRN WIRE
MMRY
MSWE
ORG/ WIRE
PNK WIRE
RED WIRE
SEAT MEMORY SWITCH
SET-
VIO WIRE
W/ 10-WAY POWER SEAT
WHT WIRE
WHT/BLK WIRE
XK (RIGHT SIDE OF LUGGAGE COMPT)
Go to component -> Driver"s memory seat circuit (2 of 2) -> LEFT LUMBAR SUPPORT ADJUSTER ASSEMBLY
